Specifications
10L Rotary Evaporator (water bath, oil bath, ball valve)1. High quality material, anti-corrosion
2. electric lifting
10L Evaporator with explosion proof device
RE-5210A 10L Evaporator with explosion proof device
Rotary Evaporator is the use of vacuum pressure, constant temperature heating conditions, using the rotating bottle constant speed rotation, the formation of large area thin film, high evaporation equipment installations.
Rotary evaporator is mainly used for pharmaceutical, chemical and bio-pharmaceutical industry concentration, crystallization, drying, separation and dissolution of coal recovery. The principle is: in a vacuum condition, constant temperature heating, to rotate bottles constant rotation, the material in the sidewall formation of large area thin film, high evaporation. Solubilization by high glass condenser vapor cooling, recovery in the collection bottle, greatly improve the efficiency of evaporation, particularly easy to use in high-temperature decomposition of the variability of biological products was concentrated and purified.
Key Features of 10L Evaporator with explosion proof device
1. Host parts: the introduction of foreign advanced transmission system, reasonable structure, durable and practical.
2. Control, temperature parts: the introduction of foreign advanced frequency control system, temperature control system to ensure accurate performance of the instrument.
3. Water bath: one made of imported stainless steel plate stamping, automatic vertical lift.
4. Sealing parts: the PTFE material selected foreign countries, through special processing technology to enhance sealing, corrosion resistance and wear resistance.
5. The main structure: high quality aluminum alloy and stainless steel, more complete and improve the equipment of a reasonable performance.
Technical parameters of 10L Evaporator with explosion proof device
type |
RE-5210A |
RE-5210 |
Down mode |
Automatic lifting |
Manual lifting |
The speed range(rpm) |
20~110 |
|
Temperature range(°C) |
(water)RT~98 |
|
condenser |
Vertical type, double serpentine tube |
|
Rotating bottle maximum capacity(L) |
10 |
10 |
Maximum capacity to collect bottles(L) |
5 |
5 |
Motor power(W) |
3180 |
3120 |
Size |
950*500*1600 |
|
Our factory is also professional in Rotary Evaporator with capacity from 50ml ~ 50L, which kind is ok for you ?
Do you need Vacuum Pump for providing vacuum condition for your experiment ?
Rotary Evaporator. Water bath or oil bath can be produced according to customers’ requests!
Customized Glass Reactor also welcome here !!!
TOPTION---Your top option !
