GIGA LX-308 Automatic Carton Box Cutting Machine Prices

GIGA LX-308 Automatic Carton Box Cutting Machine Prices thumbnail-1
GIGA LX-308 Automatic Carton Box Cutting Machine Prices photo-1
US$ 68,000 - 500,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Application:
Other, Carton making and printing
Packaging Type:
Other, In Steel Pallet
Contact Supplier Request Quote Chat Now
Shanghai Liu Xiang General Equipments Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
PORT OF CHINA
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Application Other, Carton making and printing
Packaging Type Other, In Steel Pallet
Packaging Material Other, In Steel PALLET
Automatic Grade Automatic
Driven Type Electric
Voltage 380v
Power 30-45kw
Place of Origin Shanghai, China
Brand Name GIGA-LX
Model Number LX308
Weight 9MT-26MT
Dimension(L*W*H) 8M*7M*2.2M
Certification CE
After-sales Service Provided Engineers available to service machinery overseas

Specifications

1.Touch-screen/electric dual system
2.Carton Box Cutting Machine Prices Good
3.Got CE
4.CNC adjusting difference of die cutte

LX308  Flexo Printing Slotting and Automatic Die Cutting Machine

Got CE certification

Carton Box Cutting Machine Main Functions:

  1. Lx308Suitable for middling and Small scale carton factory. All transmission gears are made of high quality alloy steel (20CrMnTi) grinded under high temperature with hardness HRC58-62 lx308
  2. Back-pushing suck blower feeding system
  3. CAPT-LOCKS union link to reduce the connect interval and keep long lasting overprint precision
  4. Functions of intelligent zero returning and memory reset, Memory order 999 is for option.
  5. Lx308Touch screen and electric control dual system.High quality materials and fittings.
  6. The transmission system adopts two oil pumps circulating lubrication

Feeding Unit.



  1.  Servo control Lead edge feeder--patent #ZL2005 2 0045628.x (Back-pushing suck blower feeding system  is option);
  2. Servo motor-quick react, lx308precision positioning, system stability and durability. Electrical camshaft supersedes mechanical style;
  3. Synchronous belt un-interval links feeding shaft with servo motor shaft, to improve feeding precision alignment; Half-wheel, quick replacing structure, to keep consistency of feeding position, and to avoid uneven wearing on the surface of feeding wheel;
  4. Pressure-free stretching feeding mechanism is the option;



 GIGA LX-308 Automatic Carton Box Cutting Machine Prices



We provide loan to below business situation
1. The value of order over RMB 1 million (including 1 million).
2. Only for boxing machine LX-308N, LX-608CN or corrugated machine production line include LXC-180NN, LXC-220H1.8N models.
3. We accept O/A (Open account), it based on the credit level of buyer's bank credit report.
4. The details please consult with our sales department.





Printing Unit

  1. Forme changing both foot switch, and/or electric control (forward / backward run), Anilox roller auto lifting device synchronous working with paper feeding system
  2. Forme roller and pressure roller are made of high quality steel, with grinded and chrome plated surface, lx307Dynamic and static balancing make steadily running, Hanging forme, make installation easy and quick, Planetary gear phasing structure
  3. Printing phase automatic 360 degree adjust by PLC, touch screen and motorized digital control.
  4. Forme roller intelligent zero returning, short cut resetting under dynamic and static condition

Slotting Unit

  1.  Pre-scoring wheel: Pre-scored paperboard will not crush
  2. Upper scoring wheel coated by polyurethane to avoid possible crush on the paperboard
  3. 7 mm thick slotting knives are made of alloy tool steel by heat treatment and finely ground, sharpened endurable teeth
  4. Bi-plate trimming knives with sharpened, endurable teeth
  5. Aluminium hand hole punch device

 Die cutting machine unit

  1. Unique speed difference compensation device makes the anvil roller slide together with mould roller so that the surface speed of anvil roller complies with it of the mould roller, to make a perfect.CNC adjusting difference system for rotary die cutting machine, which is for  option







GIGA LX-308 Automatic Carton Box Cutting Machine PricesGIGA LX-308 Automatic Carton Box Cutting Machine Prices

GIGA LX-308 Automatic Carton Box Cutting Machine Prices

GIGA LX-308 Automatic Carton Box Cutting Machine Prices





  • Mould roller and anvil roller can be apart by the air cylinder eccentric mechanism prolong the life of the cutting mould and urethane rubber
  • Rotary die cutting machine anvil roller and mould roller adopts high-grade steel with finely reground and chrome plated surface.

Stacking Unit

  1. Connection arm has manual and automatic operation methods
  2. Tension of the driving belt of connection arm can be adjusted alone; Stacking height: 1600 mm, Anti slipping belt used in the transport bed.
  3. Platform elevation and transmission motor has braking function, Carton Box Making Machine Prices are goods.
  4. A pneumatic controlled plate will pop-up to hold the coming substrate when the pre-set height reached

Model

1800/2200x1000

2500x1200/1400/1600

2800x1200/1400/1600

Max. machine speed (pcs/min)

200

160/140/120

160/140/120

Max. printing speed(pcs/min)

180

120

120

Max. feeding size(mm)

1770/2170*970

2500*1170/1370

2500*1170/1370

Skip feeding size(mm)

1770/2170*1170

2500*1370/1570/1770

2500*1370/1570/1770

Min. feeding Size(mm)

650*280

650*380/400/450

700*380/400/450

Feeding depth (mm)

2.5-10

2.5-10

2.5 - 10

Min. slot interval

Positive cut

(mm)

120*120*120*120

140*140*140*140

140*140*140*140

Reverse cut

(mm)

190*50*190*50

250*80*250*80

 250*80*250*80



Max. printing area(mm)

1750/2150*950

2450*1150/1350

2750*1150/1350

Standard printing plate thickness(mm)

7.2

7.2

7.2

*Subject to change and improvement without notice,GIGA LX-308 Automatic Carton Box Cutting Machine PricesGIGA LX-308 Automatic Carton Box Cutting Machine PricesGIGA LX-308 Automatic Carton Box Cutting Machine Prices

   GIGA LX-308 Automatic Carton Box Cutting Machine PricesGIGA LX-308 Automatic Carton Box Cutting Machine PricesGIGA LX-308 Automatic Carton Box Cutting Machine PricesGIGA LX-308 Automatic Carton Box Cutting Machine Prices

GIGA LX-308 Automatic Carton Box Cutting Machine Prices

2-4....d1-2
