GIGA LXC 5 Layers Corrugated Carton Box Machinery

Name: GIGA LXC 5 Layers Corrugated Carton Box Machinery
Brand: GIGA LX
SKU: 112008555
Availability: InStock

US$ 320,000 - 880,000 MOQ: 1 Set

Key Specifications

Condition:

New

Application:

Food, Medical, Other, Food, Medical, Machinery & Hardware

Packaging Type:

Cartons, Film

Shanghai Liu Xiang General Equipments Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Port of China

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Application Food, Medical, Other, Food, Medical, Machinery & Hardware

Packaging Type Cartons, Film

Packaging Material Plastic, Metal

Automatic Grade Automatic

Driven Type Electric

Voltage 380V

Power 300-400KW

Place of Origin Shanghai, China

Brand Name GIGA LX

Model Number LXC-250-2200-5 layers

Certification CE

After-sales Service Provided Engineers available to service machinery overseas

Specifications

rrugated box machinery
2.WIDTH: 2200MM
3.DESIGNED SPEED: 250M/MIN
4.WORKING SPEED:180-200M/MIN

GIGA LXC SWL250-2200-5 LAYERS CORRUGATED BOX MACHINERY

Specification of Corrugated machinery,corrugated carton machinery production line

1.SWL250-2200-5 LAYERS CORRUGATED CARDBOARD MACHINE
2.WIDTH: 2200MM
3.DESIGNED SPEED: 250M/MIN
4.WORKING SPEED:180-200M/MIN

Compression method oil pressure.
Corrugated box machinery outside suction with no claw style guide;
The up and down movement for upper and lower corrugated rollers, pressure roller and glue roller are controlled by oil pressure.
When Host pause, the glue roller with rotation feature to prevent glue dry.
The gap between glue roller and absorption glue roller is precision measurement, touch screen display, electric adjustment, and automatic adjustment according to the machine speed.
Independent drive box with universal joint transmission.
Cardboard corrugated box machinery roller adopts 48CrMo alloy steel, with heat treatment for hardness HRC58-62 degree, and the surface is well treated by grind; tungsten carbide corrugated roller for optional.
Corrugated box machinery and corrugated machine are also made in good quality.
Electrically insulate glue device, adjusting the width of glue sizing convenient and fast.
