Home > Products > Chemical Synthesis Reactor Series > innvoative lab Three Layers Glass Reactor TOPT-30L
innvoative lab Three Layers Glass Reactor TOPT-30L
- 300 Piece / Pieces per Month
- shanghai/zhejiang/tianjin
- Credit Card
You May Like
-
innvoative Three Layers Glass Reactor TOPT-150L
-
jacketed Three Layers Glass Reactor TTF -5L with good quality
-
good quality chemical Three Layers Glass Reactor TTF -5L
-
technical Three Layers Glass Reactor TTF -1L
-
scientific design single layer glass reactor TST-200L with good quality
-
AC motor digital single layer glass reactor TST-100L
Product Details
Condition | New | Automatic Grade | Automatic | |
Type | Tank Reactor | Place of Origin | Shaanxi, China | |
Brand Name | TOPTION | Model Number | TOPT-150L | |
Voltage | 220V | Power(W) | 180 | |
Certification | ISO, CE | Warranty | one year | |
After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
innvoative lab Three Layers Glass Reactor TOPT-30L
Three Layers Glass Reactor product description
Three glass reactor main sealing parts pure PTFE material, guarantee absolute vacuum system. Three glass reactor three layers glass design, inner into reaction menstruum do stirring reaction, interlayer can pass different cold sources (cryoprotectants, hot water or hot oil) do cycle heating or cooling reaction. Setting thermostat conditions, in confined glass reactor, can use require atmospheric or negative pressure conditions conducted stirring response and do reaction solution reflux and distillation is modern Fine Chemical Factory, biopharmaceuticals and new materials synthesized ideal test production equipment.
Key Features:
1. Three layers glass reactor using VVVF, AC Induction Motor. Speed constant, no brush, no sparks, security stable, continuous working.
2. Complete glass reactor adopts GG17 high borosilicate glass production good chemical, physical properties.
3. Glass interlayer Interface communication on hot oil through cycle do Heating Reaction, Tung on cryoprotectants can be hypothermia reaction.
4. Can normal temperature reaction, pass last tap namely quickly will reflect heat away.
5. Decentralization material mouth with flange mouth and PTFE valve, container no dead corner detachable easy solid materials outfeed.
6. 5 reactor lid, large mouth design easy clean standard mouth socket selectable assemble reflux, distillation synthesis device
Technical parameters
type
| volume (L) | Motor power (W) | Speed (r/min)
| Stirring torque(1300r/min) | Inside/outside tube diameter (mm) | Reactor vessel cover relevant opening size | ||||
center | left | right | later | before | ||||||
TOPT-150L | 150 | 370 | 10-680
| 28000g.cm | 600*550 | 50# | 40# | 34# | 34# | 29# |
TOPT-100L | 100 | 250 | 22000g.cm | 460*500 | 50# | 40# | 34# | 34# | 29# | |
TOPT-80L | 80 | 250 | 22000g.cm | 460*500 | 50# | 40# | 34# | 34# | 29# | |
TOPT-50L | 50 | 180 | 15000g.cm | 360*405 | 50# | 40# | 34# | 34# | 29# | |
TOPT-30L | 30 | 180 | 15000g.cm | 315*360 | 50# | 40# | 34# | 34# | 29# | |
TOPT-20L | 20 | 120 | 12000g.cm | 315*360 | 50# | 40# | 34# | 34# | 29# | |
TOPT-10L | 10 | 120 | 12000.g.cm | 245*260 | 50# | 40# | 34# | 34# | 29# | |
TOPT-5L | 5 | 90 | 9000.g.cm | 200*230 | 50# | 29# | 24# | 24# | 19# | |
TOPT-3L | 3 | 60 | 5000.g.cm | 200*230 | 50# | 29# | 24# | ---- | 19# | |
TOPT-2L | 2 | 60 | 5000.g.cm | 150*180 | 50# | 29# | 24# | ---- | 19# | |
TOPT-1L | 1 | 40 | 2400.g.cm | 150*180 | 50# | 29# | 24# | ---- | 14# |
