Specifications
latest single layer glass reactors1.Explosion-proof series available
2.Convenient and reliable for mobile use
Product Name: Quality best quality latest single layer glass reactors
latest single layer glass reactors Features:
1. Frequency control, AC induction motor, speed digital display constant, brushless, no spark, safe and stable, it can work continuously;
2. Supporting glass using GG17 high boron silicon material production, has a good chemical, physical properties; big bottle design, hand out cleaning;
3. PTFE (Ceramic) mechanical component sealing, proprietary technology, it can get the best vacuum degree in the market among the similar products;
4. Overall stainless steel frame structure (foot connecting parts like Tee and four-way valve are all stainless steel), compact and solid, stable and reliable without shaking when mixing;
5. Casters with brake fixed, it is convenient and reliable for mobile use;
6. The PTFE discharge valve without dead corner, solid material/liquid material can be easily released from the bottom;
7. Computer controlled thermostatic oil bath, the intelligent PID control, temperature control is accurate and convenient;
8. Integral structure is scientific design and beautiful appearance, convenient for operation;
9. Explosion-proof series available.
( We can add the cooling coil and an anti-explosion device according to user's needs)
latest single layer glass reactors Technical parameters:
| Model | TST-2L | TST-5L | TST-10L | TST-20L | TST-30L | TST-50L | TST-80L | TST-100L | TST-150L | TST-200L |
| Reaction flask(L) | 2 | 5 | 10 | 20 | 30 | 50 | 80 | 100 | 150 | 200 |
| The mouth number of the bottle | 4 | 4 | 5 | 5 | 5 | 6 | 6 | 6 | 7 | 7 |
| Stirring power(W) | 90 | 120 | 180 | 180 | 250 | 250 | 250 | 250 | 370 | 450 |
| Speed(rpm) | 0-1300 | 0-1300 | 0-720 | 0-720 | 0-720 | 0-720 | 0-720 | 0-720 | 0-720 | 0-720 |
| The diameter of Stirring bar(mm) | φ6 | φ10 | φ10 | φ10 | φ12 | φ12 | φ16 | φ16 | φ18 | φ18 |
| Heater | 1.5kw 180°C | 2kw 180°C | 2.5kw | 3kw 180°C | 4.5kw | 6kw 180°C | 7kw | 9kw | 10kw | 11kw |
| 180°C | 180°C | 180°C | 180°C | 180°C | 180°C | |||||
| Power(V) | 220 | 220 | 220 | 220 | 220 | 380 | 380 | 380 | 380 | 380 |
| Frequency-converting | no | have | have | have | have | have | have | have | have | have |
| Vacuum sealing | have | |||||||||
| ±0.2°Ccontrolling of temperature | have | |||||||||
| Discharge valve | have | |||||||||
| PTEE stirring bar | have | |||||||||
| Charging cork | have | |||||||||
| Tube for testing temperature | have | |||||||||
| Reflux condenser | optional | have | ||||||||
| Distillation condenser system | no | optional | ||||||||
| Vacuum meter | no | optional | have | |||||||
| stereoscopic stirring | have | |||||||||
| Automatic stir in CW or CCW | no | no | no | optional | have | |||||
| Mouth for muti-fanctions | no | no | no | have | ||||||
| Low mouth for taking material out | no | no | have | |||||||
| Discharging cork | no | no | have | |||||||
| Cap of heating bath | optional | |||||||||
| Corke for anti-block | no | no | no | no | have | |||||
| Increase power under lower speed | no | optional | ||||||||
| Cooling coils | no | no | optional | |||||||
latest single layer glass reactors Technology services:
1. We can design and produce equipments according to your requests!
2. Single layer glass reactor, double layers glass reactor, three layers glass reactor all welcome here!
latest single layer glass reactors pictures
latest single layer glass reactors producing process
latest single layer glass reactors packing
