Cheapest high quality latest three layer glass reactor
- 3000 Piece / Pieces per Month
- Zhejiang /Shanghai /Tianjin Port
- Credit Card
-
Side Entry Mixing Equipment
-
Small Jacketed Glass Reactor Double Layer Reaction Systems for Laboratory
-
Lab Jacketed Glass Reactor 10 Liter Chemical Reactor for Research
-
Mini Lab Jacketed Glass Reactor High Borosilicate Reaction Vessel
-
Customized Industrial Chemical Reaction Jacketed Glass Reactor
-
GG-17 Jacketed Glass Reactor Heating and Cooling Circulator Mixer Reactor
Product Details
Condition: | New | Automatic Grade: | Automatic | Type: | Reaction Kettle |
Place of Origin: | Shaanxi, China | Brand Name: | TOPTION | Model Number: | TOPT-10L |
Voltage: | 220V | Power(W): | 120W | Dimension(L*W*H): | 245*260mm |
Weight: | 58 KG | Certification: | ISO9001 | Warranty: | 1 year |
After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
Specifications
latest three layer glass reactor1.No brush, no sparks, security stable
2.For using VVVF, AC Induction Motor
Cheapest high quality latest three layer glass reactor
1. Volume:1L 2L 3L 5L 10L 20L 30L 50L 80L 100L 150L
2. Reacting tem:-80~300
3. GG17, SS,PTFE sealing,TOPTION Brand
4. University brands designated
5. Explosion-prood device is optional
6. Ac motor,brushless,no sparkle
7. Constant rotationg speed
8. Reflow and distillation system
9.chemical laboratory use
10.reaction mixing vessel
latest three layer glass reactor description
Three glass reactor main sealing parts pure PTFE material, guarantee absolute vacuum system.
Three glass reactor three layers glass design, inner into reaction menstruum do stirring reaction, interlayer can pass different cold sources (cryoprotectants, hot water or hot oil) do cycle heating or cooling reaction. Setting thermostat conditions, in confined glass reactor, can use require atmospheric or negative pressure conditions conducted stirring response and do reaction solution reflux and distillation is modern Fine Chemical Factory, biopharmaceuticals and new materials synthesized ideal test production equipment.
latest three layer glass reactor Key Features
1. Three layers glass reactor using VVVF, AC Induction Motor. Speed constant, no brush, no sparks, security staTOPTe, continuous working.
2. Complete glass reactor adopts GG17 high borosilicate glass production good chemical, physical properties.
3. Glass interlayer Interface communication on hot oil through cycle do Heating Reaction, Tung on cryoprotectants can be hypothermia reaction.
4. Can normal temperature reaction, pass last tap namely quickly will reflect heat away.
5. Decentralization material mouth with flange mouth and PTFE valve, container no dead corner detachaTOPTe easy solid materials outfeed.
6. 5 reactor lid, large mouth design easy clean standard mouth socket selectaTOP Te assem TOPT reflux, distillation synthesis device
latest three layer glass reactor Technical parameters
type
| volume (L) | Motor power (W) | Speed (r/min)
| Stirring torque(1300r/min) | Inside/outside tube diameter (mm) | Reactor vessel cover relevant opening size | ||||
center | left | right | later | before | ||||||
TOPT-150L | 150 | 370 | 10-680
| 28000g.cm | 600*550 | 50# | 40# | 34# | 34# | 29# |
TOPT-100L | 100 | 250 | 22000g.cm | 460*500 | 50# | 40# | 34# | 34# | 29# | |
TOPT-80L | 80 | 250 | 22000g.cm | 460*500 | 50# | 40# | 34# | 34# | 29# | |
TOPT-50L | 50 | 180 | 15000g.cm | 360*405 | 50# | 40# | 34# | 34# | 29# | |
TOPT-30L | 30 | 180 | 15000g.cm | 315*360 | 50# | 40# | 34# | 34# | 29# | |
TOPT-20L | 20 | 120 | 12000g.cm | 315*360 | 50# | 40# | 34# | 34# | 29# | |
TOPT-10L | 10 | 120 | 12000.g.cm | 245*260 | 50# | 40# | 34# | 34# | 29# | |
TOPT-5L | 5 | 90 | 9000.g.cm | 200*230 | 50# | 29# | 24# | 24# | 19# | |
TOPT-3L | 3 | 60 | 5000.g.cm | 200*230 | 50# | 29# | 24# | ---- | 19# | |
TOPT-2L | 2 | 60 | 5000.g.cm | 150*180 | 50# | 29# | 24# | ---- | 19# | |
TOPT-1L | 1 | 40 | 2400.g.cm | 150*180 | 50# | 29# | 24# | ---- | 14# |
latest three layer glass reactor pictures
latest three layer glass reactor producing process
latest three layer glass reactor packing
