Specifications
new three layer glass reaction kettle1.No brush, no sparks, security stable
2.For using VVVF, AC Induction Motor
Creative good price new three layer glass reaction kettle
1. Volume:1L 2L 3L 5L 10L 20L 30L 50L 80L 100L 150L
2. Reacting tem:-80~300
3. GG17, SS,PTFE sealing,TOPTION Brand
4. University brands designated
5. Explosion-prood device is optional
6. Ac motor,brushless,no sparkle
7. Constant rotationg speed
8. Reflow and distillation system
9.chemical laboratory use
10.reaction mixing vessel
new three layer glass reaction kettle description
Three glass reactor main sealing parts pure PTFE material, guarantee absolute vacuum system.
Three glass reactor three layers glass design, inner into reaction menstruum do stirring reaction, interlayer can pass different cold sources (cryoprotectants, hot water or hot oil) do cycle heating or cooling reaction. Setting thermostat conditions, in confined glass reactor, can use require atmospheric or negative pressure conditions conducted stirring response and do reaction solution reflux and distillation is modern Fine Chemical Factory, biopharmaceuticals and new materials synthesized ideal test production equipment.
new three layer glass reaction kettle Key Features
1. Three layers glass reactor using VVVF, AC Induction Motor. Speed constant, no brush, no sparks, security staTOPTe, continuous working.
2. Complete glass reactor adopts GG17 high borosilicate glass production good chemical, physical properties.
3. Glass interlayer Interface communication on hot oil through cycle do Heating Reaction, Tung on cryoprotectants can be hypothermia reaction.
4. Can normal temperature reaction, pass last tap namely quickly will reflect heat away.
5. Decentralization material mouth with flange mouth and PTFE valve, container no dead corner detachaTOPTe easy solid materials outfeed.
6. 5 reactor lid, large mouth design easy clean standard mouth socket selectaTOP Te assem TOPT reflux, distillation synthesis device
new three layer glass reaction kettle Technical parameters
|
type
|
volume (L) |
Motor power (W) |
Speed (r/min)
|
Stirring torque(1300r/min) |
Inside/outside tube diameter (mm) |
Reactor vessel cover relevant opening size |
||||
center |
left |
right |
later |
before |
||||||
TOPT-150L |
150 |
370 |
10-680
|
28000g.cm |
600*550 |
50# |
40# |
34# |
34# |
29# |
TOPT-100L |
100 |
250 |
22000g.cm |
460*500 |
50# |
40# |
34# |
34# |
29# |
|
TOPT-80L |
80 |
250 |
22000g.cm |
460*500 |
50# |
40# |
34# |
34# |
29# |
|
TOPT-50L |
50 |
180 |
15000g.cm |
360*405 |
50# |
40# |
34# |
34# |
29# |
|
TOPT-30L |
30 |
180 |
15000g.cm |
315*360 |
50# |
40# |
34# |
34# |
29# |
|
TOPT-20L |
20 |
120 |
12000g.cm |
315*360 |
50# |
40# |
34# |
34# |
29# |
|
TOPT-10L |
10 |
120 |
12000.g.cm |
245*260 |
50# |
40# |
34# |
34# |
29# |
|
TOPT-5L |
5 |
90 |
9000.g.cm |
200*230 |
50# |
29# |
24# |
24# |
19# |
|
TOPT-3L |
3 |
60 |
5000.g.cm |
200*230 |
50# |
29# |
24# |
---- |
19# |
|
TOPT-2L |
2 |
60 |
5000.g.cm |
150*180 |
50# |
29# |
24# |
---- |
19# |
|
TOPT-1L |
1 |
40 |
2400.g.cm |
150*180 |
50# |
29# |
24# |
---- |
14# |
|
new three layer glass reaction kettle pictures
new three layer glass reaction kettle producing process
new three layer glass reaction kettle packing
