Specifications
KBJX stripe concrete block machine for stripe tiles500*250mm, 600*300mm, 400*200mm
stripe lines can be adjusted
KBJX stripe concrete block machine for stripe tiles
(stripe paver machine, stripe paving making machine, stripe stone machine, stripe block making machine)
Raw material for KBJX stripe concrete block machine for stripe tiles
Raw materials | Specification | Ratio(kg) | Notes |
Cement | common | 50 |
|
Additive | Water-reducing agent | 0.5~1.0 | optional |
Fly ash | Should be qualified | 10~30 | optional |
Stripe pavers / stripe blocks are made by two machines, tile making machine + striping machine = KB-125E/500 + KB-125TWA
KB-125E/500 specification:
| Equipment type | Model 500 |
| moulding speed | 5-6pcs/min |
| main frame power | 7.5kw |
| main frame weight | 7T |
| external dimension | 3300*1680*2700mm |
KB-125TWA specification:
| External dimension | 3000*880*1580mm |
| Grinding head diameter | Ø338mm |
| Cutter blade diameter | Ø200mm |
| motor power | 21.8KW |
| Equipment | pump or tap water |
| weight | 3.5T |
Total production line picture for KBJX stripe concrete block machine for stripe tiles
equipments composed for KBJX stripe concrete block machine for stripe tiles
| 1 | Moulding machine | 1 set |
| 2 | constant feeder machine | 1 set |
| 3 | blender | 1 set |
| 4 | elevator machine | 1 set |
| 5 | air compressor | 1 set |
| 6 | stripping machine | 1 set |
work flow of KBJX stripe concrete block machine for stripe tiles
Work flow: Elevating--- Mixing --- Fixed-quantity filling --- Pressure forming --- Mould unloading --- Forming tiles --- Onto the tiles shelf ---Maintenance (24 hours) --- Stacking --- Natural maintenance --- Ink jetting --- Finished products.
finished stripes
Multi-functional samples of tiles by chaning mould
Factory:
for details information, pls kindly feel free to contact following:
