Specifications
KB-125E/600 quick delivery Terrazzo tile making machine / terrazzo tile machine2000pcs per 8 hours
300*300mm to 600*600mm
KB-125E/600 quick delivery Terrazzo tile making machine / terrazzo tile machine
(floor tile making machine, tile machine, forming machine)
specification for KB-125E/600 Terrazzo tile making machine / terrazzo tile machine
| Technical data | |
| moulding presure | 125T |
| moulding speed | 5-8pcs/min,more than 3000pcs/shift |
| main frame weight | about 7T |
| external dimension | 2700*1600*2480mm |
| Troduction capability | |
| floor tile | 5-8 pcs/min |
| Artifical stone | 5-8 pcs/min |
| roof tile | 5-8 pcs/min |
full production line of KB-125E/600 Terrazzo tile making machine / terrazzo tile machine
mixer
elevator
feeder
tile moulding machine
polishing machine
production process for KB-125E/600 Terrazzo tile making machine / terrazzo tile machine
Our KB-125E/600 Terrazzo tile making machine / terrazzo tile machine have following characters:
1. Its merits includes the high forming rapid, the high output, the PLC automatic control, the reliable performance, the convenient operation, the fully hydropneumatic driving, the high producing speed of 8 pcs/min, the high rate of finished products, and the excellent performance-price ratio
2. It's made of cement sand stone debris chemical color, formed by extruding, with the nice shape, various types, great stability and exact size.
3.It's multifunctional. By changing the mould, it could be used to produce paving slabs Blind way brickParking lot bricklawn brick , etc.
4. KB-125E/600 Terrazzo tile making machine also can make roof tiles. includes main tile, ridge tile, end tile...etc
5 KB-125E/600 Terrazzo tile making machine also can make TURBSTONE with length reach 100cm more. sand, cement, cobblestones and water
6. each kind tile has module, we can open any modules of designs from customers
7.about tile, single layer & double layers are both available
8.very easily operated by workers. one machine need 2-3 people. workers need 2-3 hous are able to learn completely.
Typical floor tiles which KB-125E/600 Terrazzo tile making machine makes:
| Roma Style | Spanish Style | Striper Style | Hexagon tile |
| 300×300mm | 400×400mm | 500×250mm | 600×540mm |
| Weight: 7kg | Weight: 9kg | Weight: 8kg | Weight: 27kg |
| Cement:Fly ash (1.8-2):1 | Cement:Fly ash (1.8-2):1 | Cement:Fly ash (1.8-2):1 | Cement:Fly ash (1.8-2):1 |
| Unit volume 11.1parcel/m2 | Unit volume 6.25parcel/m2 | Unit volume 8.0parcel/m2 | Unit volume 3.1parcel/m2 |
| Capacity≥2200N | Capacity≥2200N | Capacity≥2200N | Capacity≥2200N |
KB-125E/600 Terrazzo tile making machine / terrazzo tile machine floor tiles sample:
functional products sample of roof tiles :
our company
for details information pls contact following:
