Specifications
1.Standard:IEC/EN60898-12.Mounting:On Din Rail Fn60715(35mm)
3. Connection: From Top And Bottom
XMM8 c16 Electronic circuit breaker :Protection and control of circuit against overload and short circuit,In building installation-such as houses,offices,commercial complex,motor system(D curve) and industrial installation-for switching,control,protection and regulation of electrical circuits.Also in switchgear panels,railway and marine application.
1.In compliance with IEC/EN60898-1.
2.Breaking Capacity:10000A
3.With indicator function in the contact position.
4.Transparent cover designed to carry label.
5.Connecting function od double busbar,to adapt to wider use of premises.
6.Maximum connecting ability of 25mm²,wiring torque 3Nm,applicable to a variety of installing equipments,
wiring stronger.
7.Protection class:IP20
Electrical Features |
Standard |
|
IEC/EN60898-1 |
Rated Current In |
A |
63 80 100 125 |
|
Poles |
|
1P 2P 3P 4P |
|
Rated Voltage Ue |
V |
230/400 |
|
Insulation Voltage Ui |
V |
500 |
|
Rated Frequency |
Hz |
50/60HZ |
|
Rated Breaking Capacity |
A |
10000 |
|
Rated Impulse Withstand Voltage(1.2/50)Uimp |
V |
6000 |
|
Dielectric Test Voltage At And Ind. Freq For 1 Min |
Kv |
2 |
|
Pollution Degree |
|
2 |
|
Themo-Magnetic Release Characteristic |
|
B C D |
|
Mechanical Features |
Electrical Life |
|
8000 |
Mechanical Life |
|
20000 |
|
Contact Position Indicator |
|
Yes |
|
Protection Degree |
|
IP20 |
|
Reference Temperature Of Setting Of Thermal Element |
°C |
30 |
|
Ambient Temperature(With Daily Average ≤35°C) |
°C |
-5~+40 |
|
Storage Temperature |
°C |
-25…+70 |
|
Installation |
Terminal Connection Type |
|
|
Terminal Size Top/Bottom For Cable |
Mm² Awg |
25 18-3 |
|
Terminal Size Top/Bottom For Busbar |
Mm² Awg |
25 18-3 |
|
Tightening Torque |
N*M IN-IBS |
3.0 22 |
|
Mounting |
|
On Din Rail Fn60715(35mm) By Means Of Fast Clip Device |
|
Connection |
|
From Top And Bottom |
3. Details
4. Package and Others
Carton
Testing room
Production line
Certification
