For Micropump Precision Zirconia Ceramic Gear Shaft
US$ 0.1 - 10
MOQ: 100 Pieces
Key Specifications
Get Latest Price
Brand Name:
hxpceramics
Model Number:
ceramic gear shaft
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
For Micro Pump Precision Gear Shaft Driving Ceramic ZirconiaUS$ 0.1 - 10MOQ: 100 Pieces -
High Wear Resistant Ceramic Tube Industrial Alumina Ceramic Bearing RingUS$ 0.1 - 50MOQ: 100 Pieces
-
Industrial Alumina Ceramic Bearing Ring/High Alumina Ceramic TubeUS$ 0.1 - 10MOQ: 100 Pieces
-
High Hardness Zirconia Ceramic Plunger Zta PartsUS$ 0.1 - 2.8MOQ: 100 Pieces
-
95% 99.5% Alumina Ceramic Tube &Zirconia Ceramic PistonNegotiableMOQ: 100 Pieces
Brand Name
hxpceramics
Model Number
ceramic gear shaft
Specifications
For Micropump precision zirconia ceramic gear shaft-Good wear resistance
-High hardness
-High strengh
-Precision processing
For Micropump precision zirconia ceramic gear shaft
Features:
1.Use temperatures up to 2400°C
2. High density
3. High hardness
4. Low thermal conductivity
5. Chemical inertness
6. Resistance to molten metals
7. Good Wear resistance
8. High fracture toughness
We can supply the products according to customer's drawings, samples and performance requirement.
Zirconia ceramic are used in shaft , plunger, sealing structure, auto mobile Industrial, oil drilling equipment, Insulation parts in electrical equipment , ceramic knife, ceramic hair clipper spare parts, with high density, bending strength and breaking tenacity.
| Performance For Industrial Ceramic | |||
| Item |
Unit | Zirconia | |
| Physical Characteristics | Heat resistance | 0C | 2200 |
| Bulk density | g/cm3 | 6.05 | |
| Water absorption | % | 0 | |
|
Mechanical Characteristics |
Flexural strength | Mpa | 1000 |
| Hardness vickers | Gpa | 89 | |
| Elastic modulus | Gpa | 200 | |
| Poisson’s ratio | 0.31 | ||
| Thermal Characteristics | Linear expansion coefficient | (20-5000C) 10-6/0C | 10 |
| Thermal conductivity | w/(m.k) | 2.5 | |
| Specific Heat |
*10-3J/(kg*K) | 0.5 | |
| Electrical Characteristics | Dielectric constant (1MHZ) | - | N.A. |
| Dielectric loss angle | *10-4 | N.A. | |
| Dielectric strength |
*106V/m | N.A. | |
| Processing technology | |||
| Process range (mm) | |||
| Outside Diameter | 1---300 | ||
| Inside Diameter | 0.5---300 | ||
| Length | 0.5---600 | ||
| Accuracy of working (mm) | |||
| Perpendicularity | 0.001 | ||
| Concentricity | 0.001 | ||
| Roundness | 0.0005 | ||
| Straightness | 0.005 | ||
| Parallelism | 0.01 | ||
| Planeness | 0.005 | ||
| Roughness | 0.005 | ||
| Fit clearance | 0.005 | ||
