Dana Steel( Division of DANA GROUP - UAE) is an ISO 9001:2008 certified manufacturer of Insulated Sandwich Panels in UA.E.Types of Sandwich Panel manufcatured by Dana Steels based in U.A.E , Dubai are :-
1. PU/PIR Foam Sandwich Panel for Roof(Corrugated type - DCP 35/200 | DCP 45/250 | DCP 45/150 ) & Wall(Flat type -DFP)
2. Rockwool Sandwich Panel
3. Aluminium Sandwich Panel
CALL/WHATSAPP NOW :- 00971-50-7983153( Mr Ankur ) or email info ( at the rate) danagroups ( dot) com
The unique sandwich construction of the panel is a result of injection of rigid polyurethane foam at high density between two rigid facings. Combinations of a wide choice of best quality facing materials offer the customers a choice of sandwich panels to choose from. Some of the facings provided by DANA include :-
- Corrugated Cladding sheet: - ( PPGI/PPGL/PPAL) or ( MFGI,MFGL,MFAL) -- Pre-painted(PP) or Mill finish(MF) in Aluminum, Alu-zinc and GI steel
- Bottom Liner sheet: - ( PPGI/PPGL/PPAL) or ( MFGI,MFGL,MFAL) -- Pre-painted or mill finish in Aluminum, Alu-zinc and GI steel or aluminum foil backed craft paper
- Insulation Material:-PUF – Polyurethane foam (B2|B3) ,Polyisocyanurate(PIR),Rock wool/Mineral Wool in Thicknesses 35mm,40mm,50 mm,75mm,100mm,125mm and 150 mm.
Polyurethane Foam ( PUF/PU), polyisocyanurate (PIR) is sandwiched between two metal or aluminium sheets.
B-3 and B-2 Type PU is provided. B-3 is regular type PU and B-2 is Fire Self extinguising type.
Fire reaction of PIR is better than B-3 and B-2 Type PU.
DANA supplies sandwich panels & it's accessories based on the client's chosen parameters such as weight, strength, durability, surface finish, colour and thermal insulation properties.Our Experienced engineers take into mind the K & U values,Fire class,Structural Load bearing capabilities while recommending the right choice for the job.
Sandwich panels are light in weight , have high mechanical strength ,strong corrosion resistance, high durability, and weather fastness, etc. The sandwich panel has excellent insulating performance: heat insulation, sound insulation, waterproof performance, etc. It is easy to install and can be used many times over.
Some of applications for which we have provided Sandwich Panels in U.A.E , Dubai , Abu Dhabi , Sharjah , KSA , Saudi Arabia , GCC covering Kuwait , Bahrain , Oman , Qatar , Africa regions namely Nigeria , Kenya , Afghanistan .
1. Sandwich Panels for roof – Corrugated
2. Sandwich Panels for walls – Flat
For insulated partitions in walls in Factories , storages , exhibition halls , gymnasiums , big halls – Sandwich panels for insulated partitions
3. Lightweight Sandwich Panels for ceilings
4. Sandwich Panel Prefab House – Pre Fab , Modular houses
5. Cheap Industrial Shed Construction
