full HD loop Recording Car Dash Camera

Specifications

1)Super small design
2)Full HD 1080P 1920*1080
3)120 degree wide view-angle
4)Image sensor:5.0MP high resolution CMOS sensor



The Parameters of car camcorder hd



Screen	2.0 inch 4:3 TFT LCD display (960x240)
CPU	Ambarella A2S60+MI5100  FULL HD 1080P
Viewing angle	120 degree wide angle
Sensor	5.0MP High resolution CMOS sensor
Storage	SDHC up to 32GB
Video Resolution	1920*1080,30fps,3.6GB/Hour;                                                    1440*1080,30fps,2.8GB/Hour;                                              1280*720,30fps, 2.4GB/Hour
Video Frame Rate	30FPS (1080P)
File Format	Image: JPEG     Video :  MOV (H.264 decoding format)
Power-off File Recovery Function	Support
Motion Detection	Support
Date time mark	Support
Memory Card	Support up to 32G TF Card
HDMI	Optional Support
AV-OUT	Optional Support
TV Standard	NTSC/PAL
USB	Support
Audio Recording	Support
Weight	50g (exclude external camera)
Surface	Spray Painting
Device Dimension	5.3 x 4.8 x 4.0mm
Language	English/French/ Spanish/ Portuguese/ German/ Italian/ Simplified Chinese/ Traditional Chinese/ Russian/ Japanese



Overall Features:

•  Super Small Design

•  Full HD 1080P 1920 x 1080 (Ambarella A2S60+MI5100)

•  120 degree wide view-angle, 1920*1080P Full HD

•  2.0 inch 4:3 TFT LCD display (960x240)

•  Image Sensor: 5.0MP High resolution CMOS sensor

•  Lens: fixed focal lens, 3.0 aperture, focal length: 7.45mm

•  Recording resolution:  1920*1080,30fps, 3.6GB/Hour;                                              1440*1080,30fps,2.8GB/Hour;

1280*720,30fps, 2.4GB/Hour;

•  Video format: MOV (H.264 decoding format)

•  Adjustable cycle recording time slice options: 1min, 3min, 5min, off

•  Recording mode: automatic records when car power is on

•  After car power is off, Li-ion battery will supply 10sec. power to prevent video files loosing

•  Support motion detection

•  Support EIS electronical Anti-shake

•  Support digital zoom: Up to 4x (Lower Resolution is Available.)

•  Support seamless cycle recording, over-write first file if memory is full

•  Snapshot photo Resolution: 3MP, 5MP, 8MP, 12MP(4000x3000) in JPEG format

•  Support real time playback and video file protection

•  Support Real Time & Date display on video and snapshot picture

•  Date Stamp: ON/OFF

•  Micro SD card socket: support Micro SDHC up to 32GB

•  Built-in microphone

•  Built-in 4 IR LED for night vision

•  Control buttons: Menu, OK, UP, Down, ON/OFF, Reset

•  OSD Languages: English/Russian/Chinese(S/T)

•  Connecting ports: Mini USB port, HDMI

•  USB port: Support USB2.0 connect to computer for upgrade and backup

•  Power supply: Car charger power supply; rechargeable Li-ion battery(3.7V, 650mAh),max 1.5 hours power supply from battery.

•  Power input: DC 5V 2A, equiped with overvoltage protection

•  Work temperature: - 20°~ 65° centigrade

•  Package Contents: Car DVR, Suction mount, Car charger(cable length: 4meters), HDMI cable, Manual(English)

•  Unit dimension: 5.3 x 4.8 x 4.0mm





package:

Standard gift box + blister (inside)

gift box size: 160*150*80mm

Weight: 530g(Full package)

Carton size:   35*32.5* 42cm

QTY: 20pcs/CTN

N.W: 11.0 Kg

G.W.:12.0 Kg
