KAMAX 5kw Powerful Diesel Generator
US$ 460 - 510
MOQ: 72 Sets
Key Specifications
Get Latest Price
Place of Origin:
Jiangsu, China
Brand Name:
KAMAX
Model Number:
KDE6500T
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
KAMAX 2KVA PORTABLE DIESEL GENERATORUS$ 230 - 310MOQ: 1 Set -
KAMAX 5 KVA PORTABLE DIESEL GENERATORUS$ 370 - 410MOQ: 50 Sets
-
KAMAX 5 KVA PORTABLE DIESEL GENERATORUS$ 370 - 410MOQ: 50 Sets
-
KAMAX 3KVA PORTABLE OPEN GENERATORUS$ 290 - 330MOQ: 50 Sets
-
KAMAX 2.8KVA PORTABLE OPEN GENERATORUS$ 290 - 330MOQ: 50 Sets
Place of Origin
Jiangsu, China
Brand Name
KAMAX
Model Number
KDE6500T
Output Type
AC Single Phase
Speed
3000/3600RPM
Frequency
50/60HZ
Rated Power
4.5kva
Rated Voltage
230v
Rated Current
39.1A
| Diesel generator set KDE6500T | ||
| Model | KDE6500T | |
| Frequency (Hz) | 50 | 60 |
| Output power (KVA) | 4.5 | 5 |
| Max. Power(KVA) | 5 | 5.5 |
| Voltage (V) | 115/230 | 120/240 |
| Current (A) | 39.1/19.6 | 41.7/20.8 |
| Engine speed (r/min) | 3000 | 3600 |
| Phase | single | |
| Power factor(cosφ) | 1 | |
| Excitation system | Self-excited constant voltage | |
| Noise level (7m) | DB (A): 72 | |
| Fuel tank capacity (L) | 15 | |
| Structure | Silent | |
| Panel | Ordinary | |
| Outputsocket | Two | |
| DC12V output | Terminal post | |
| Engine Model | KA186FAE | |
| Bore*stroke (mm) | 86 *72 | |
| Displacement (L) | 0.418 | |
| Power (KW) | 5.7/3000 | 6.3/3600 |
| Fuel consumption rate (g. KW/h) | 275.1 | 281.5 |
| Compression ratio | 19 | |
| Lubrication system | Spring | |
| Engine starting system | Electric starter | |
| Diesel oil model | Summer: 0#, winter: -10# | |
| Lube oil model | SAE10W-30 (above CD grade) | |
| Lube oil capacity (L) | 1.65 | |
| Battery capacity(V-AH) | 12V-36Ah | |
| Net weight (KG) | 170 | |
| Dimension(L*W*H) | 970×560×770 | |
