BI-1600 AC DC Digital MCU Inverter HF TIG MMA 2 in 1 Welder

BI-1600 AC DC Digital MCU Inverter HF TIG MMA 2 in 1 Welder photo-1
US$ 300 - 400 MOQ: 20 Sets
Key Specifications
Get Latest Price
Condition:
New
Place of Origin:
Beijing, China
Brand Name:
ALAND
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai Tianjin
Delivery Detail:
Delivery time depends on order quantity.
Condition New
Place of Origin Beijing, China
Brand Name ALAND
Model Number BI-1600
Arc Current 5-160A
Pulse Frequency 50/60Hz
Pilot Arc Current 16.4/26.4A
Rated Duty Cycle 60-100%
Motor Type DC Motor
Dimensions 435*180*265mm
Usage stick welding, TIG welding
Voltage 220/230/240V
Power(W) 2.9/4.7KW
Certification GS/CE/EMC/ROHS

Specifications

AC DC Digital MCU Inverter TIG MMA 2in1 Welder
- IGBT & PWM
- Selective:EMC
- Intelligent HF
- Certificate: GS/CE/EMC/RoHS





Product Description





BI-1600   AC DC Digital MCU Inverter HF TIG MMA 2 in 1 Welder



Features:

- Adopt IGBT & advanced PWM inverter technology
- Using high performance MCU, speedy, excellent real-time response
- DC MMA,AC/DC Pulse TIG functions
- EMC function can be selective.
- Digital display, easy operation
- Each welding parameter can be adjusted in real-time
- Intelligent HF, brush strokes arc Ignition technology, high success rate
- Welder pulse parameters accurate
- protection function based on the fuzzy technology

Application:
- Nuclear power installation, pipe installation, petrochemical, shipbuilding, automobile, boiler, pressure vessel, aviation, etc.
- Apply to all position welding of stainless steel, carbon steel, alloy steel, Copper, Titanium, Aluminum etc.
- Usd by DIYer.



Specifications:

Model

BI-1600(MMA TIG)

Rated Input Voltage(V)

1phase,230±15%

Input Frequency(Hz)

50/60

Rated Input Power(KVA)

2.9

No-load Voltage(V)

56

Rated Output Voltage(V)

16.4(TIG)                     26.4(MMA)

Output Current Range (A)

5-160

Duty Cycle(%)

40C°160A @ 40%
40C°140A @ 100%

Efficiency(%)

80

Insulation Class

F

Protection Class

Ip23S

Weight(Kg)

9

Dimension(mm)

435x180x265





Optional Accessories

TIG Torch, Electrode Holder, Earth clamp, Welding Cable, Welding Mask, Steel Brush
