Double take-up
Motor of double take-up :Z4-160-31, DC 30kw×2,1500r/min
Traverse motor : 1.1KW
Brake : air pressure to hydraulic pressure, disk type
Bobbin loading : button operation, shaftless,
bobbin cones clamping, safety pin protection
Dimension L×W×H : approx.3320×3237×2570
Weight : abt. 4200 kgs
Compressed air:
Working pressure : 0.2~0.4 Mpa
Temperature : ≤30℃
Flow :12-18m3/hr
Humidity : ≤ 2-3%
Bobbin loading and unloading, bobbin clamping, the safety pins are controlled in pneumatic way.
Traverse width, wire pitches are adjustable.
Assembly Workshop
Mechanical Strength
Certifications
Packing: well packed on steel pallets in 1x 20HC containers.
Suitable for long distance ocean freight transportation and to change of climate, well protected against moisture and shocks.
Terms of payment:
- 40% at contract, 55% before shipment, 5% after acceptance test at user site in 1 month by T/T.
- Payment by an irrevocable L/C is acceptable.
1. Any inquire will be replied within 24 hours.
2 .Prodessional manufacture,welcome to visit our website
3. Any your idea on machine,we will help you to design and put it into production.
4. High quality,fashion designs,reasonable competitive price,fast lead time.
5. After-sale service.
a. All products will have been strictly quality checked in house before packing.
b.1 year warranty.
c. Engineers available to service machinery overseas
