The supercapacitor with large-capacity and high-power produced by Liyuan Company filled the domestic blank of supercapacitor products. Compared with similar international products, the technology has significant breakthrough in the volume and power density, it is cost-effective, every performance index takes the domestic leading position. Liyuan’s large-capacity, high power super-capacitor industrialization technology is top-ranked in the nationwide.
Model |
Rated Voltage (V) |
Capacitance (F) |
Rated Current (A) |
Max. Current (A) |
ESRDC (mΩ) |
24hrs Peak Current (mA) |
24hrs Holding Voltage(V) |
Size D×L(mm) |
P/d (mm) |
CPP2R7010 |
2.7 |
1 |
0.25 |
≥1 |
140 |
0.006 |
≥2.1 |
Φ8×14.5 |
3.7/0.5 |
CPP2R7020 |
2.7 |
2 |
0.5 |
≥2 |
120 |
0.008 |
≥2.2 |
Φ8×17 |
3.7/0.5 |
CPP2R73R3 |
2.7 |
3.3 |
0.75 |
≥3 |
120 |
0.015 |
≥2.3 |
Φ8×25 |
3.7/0.5 |
CPP2R7060 |
2.7 |
6 |
1.1 |
≥4.5 |
100 |
0.030 |
≥2.4 |
Φ10×25 |
5.5/0.7 |
CPP2R7100 |
2.7 |
10 |
2.2 |
≥9 |
40 |
0.040 |
≥2.4 |
Φ12×26 |
5.5/0.7 |
CPP2R7200 |
2.7 |
20 |
4.5 |
≥18 |
30 |
0.080 |
≥2.5 |
Φ16×24 |
5.5/0.7 |
CPP2R7300 |
2.7 |
30 |
6 |
≥24 |
30 |
0.130 |
≥2.5 |
Φ16×32 |
5.5/0.7 |
CPP2R7600 |
2.7 |
60 |
8 |
≥32 |
15 |
0.140 |
≥2.5 |
Φ19×42 |
8.5/0.9 |
Working Temperature |
-40°C~+70°C |
Rated Voltage |
2.7V |
surge voltage |
3.0V |
Max. permissible deviation of capacity |
-10%~20% |
Max. permissible deviation of resistance |
-50%~50% |
Temperature characteristic |
+70°CC/C≤10%,ESR≤ESR 0 -40°CC/C≤20%,ESR≤2 ESR 0 |
Heat-characteristics (durability) |
1000h,+70°C±2,Rated Voltage,C/C≤30%,ESR≤2 ESR 0 |
High-temperature properties of opeed |
1000h,+70°C±2,C/C≤30%,ESR≤2 ESR 0 |
Steady-state of moist heat |
+40°C±2,90~95%RH,240h,C/C≤30%,IL≤2 ESR 0,ESR≤2 ESR 0 |
Holding Voltage |
18°C~25°C,After constant voltage24hrs,Standing24hrs,Two-terminal voltage values |
Cycle life |
Voltage 2.7V~1.35V,18°C~25°C,Moist≤85%,Charge-discharge cycle 500,000times,C/C≤30%,ESR≤2 ESR 0 |
