Heavy-Duty Aluminum Wire Drawing Machine

Heavy-Duty Aluminum Wire Drawing Machine thumbnail-1
Heavy-Duty Aluminum Wire Drawing Machine photo-1
Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
Inlet Diameter:
8.00
Outlet Diameter:
1.2-3.5
Contact Supplier Request Quote Chat Now
Kunshan City Hongtai Machinery & Electric Equipment Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Inlet Diameter 8.00
Outlet Diameter 1.2-3.5
Place of Origin Jiangsu, China
Brand Name HONTA
Model Number HT-450-13D
Voltage 380, 415V
Certification CE
Warranty 1 year
After-sales Service Provided Overseas third-party support available

1. Drawing Machine

Inlet diameter: Φ9.5 mm

Outlet diameter: Φ1.7mm - Φ4.8mm

Drawing speed: Max. 30 m/s

Drawing passes:13, each die with emulsion spraying

Diameter of finished capstan: Φ 450mm

Area reduction: 1.238

Max. die dimension: Φ43 diameter × 35 thickness

installed power: 630 KVA

normal electricity consumption: approx. 360 kWh

cooling water consumption : approx. 40 m3 /hr

Compressed air : 12 -18 m3 /hr

Bobbin : DIN 630 ( Drawing will be provided by users)

Operation direction : from left to right

Noise level :< 85 dbA (Except for main motor )

Line dimension (L X W X H) : approx.25700×4600×4500

Hardness of drawing capstans : ≥850, long service life.

Main motor : Z4-315-22,280kw,1000r/min, DC

Motor of finished capstan : Z4-200-21,75kw,1500r/min, DC

Helical tooth wheel : marterial 20CrMnTi; carburizing and quenching

Cooling type : capstans fully immerged

The last die holder : rotational

Transmission motor and finished capstan : by helical toothed belt

Lubricating oil tank : L×W×H=1.4×1.4×1.2=2.35m3

Pump for lubricating oil :CBZ-70A 1.3Mpa 3kw

Heat exchanger for lubricating oil : BR0.1-1.6-3-N; Path 25; area 3 m2



2. Double Take-up

Motor of double take-up : Z4-160-31,30kw×2,1500r/min

Installed power of spooler : DC 30 Kw X2

Traverse motor : 1.1kW

Limit motor : AC 30W X2

Brake : air pressure to hydraulic pressure, disk type

Bobbin loading : button operation, double shafts clamping,safety pin protection

Dimension L×W×H : approx. 3320×3237×2570

Weight : abt. 4200 kgs
