HT-24DT High Speed Fine Wire Drawing Machine With Annealer Wire Drawing Machine
Negotiable
MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Jiangsu, China
Brand Name:
HONTA
Model Number:
HT-24DT
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
HT-24DT Fine Wire Drawing Machine With Annealer Wire and Cable EquipmentNegotiableMOQ: 1 Set -
HT-24DT Fine Wire Drawing Machine With AnnealerUS$ 20,000 - 30,000MOQ: 1 Set
-
HT-22DS Fine Wire Drawing Machine for CuNegotiableMOQ: 1 Set
-
HT-22DTS Fine Wire Drawing Machine With AnnealerNegotiableMOQ: 1 Set
-
Small Wire Drawing Machine Jiangsu Kunshan HONTA Manufacturer of Wire and Cable MachineUS$ 5,000 - 15,000MOQ: 1 Set
Place of Origin
Jiangsu, China
Brand Name
HONTA
Model Number
HT-24DT
Usage
Drawing
Main technical data of HT-24DT fine wire drawing machine:
Inlet diameter: Φ1.0
Outlet diameter: Φ0.25-Φ0.08mm
Drawing line speed: 1800mpm/max
Main motor power: 11KW
Annealing current: 250A
Annealing voltage: 65V
Take-up motor power: 4KW
Annealer method: DC three-section annealing
Suitable diameter of spool: Φ300mm
Brake way: Magnetic brake
Machine dimention: 1800L X 1400W X 2100H (mm) Machine weight: 3000kgs
