Extremely Fine Wire & Supper Wire Drawing Machine

Extremely Fine Wire & Supper Wire Drawing Machine thumbnail-1
Extremely Fine Wire & Supper Wire Drawing Machine photo-1
Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Jiangsu, China
Brand Name:
HONTA
Model Number:
HT-12DW
Contact Supplier Request Quote Chat Now
Kunshan City Hongtai Machinery & Electric Equipment Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Jiangsu, China
Brand Name HONTA
Model Number HT-12DW
Usage Drawing

  Main technical data of the Extremely fine wire & supper wire drawing machine:

·      inlet diameter:Φ0.018-Φ0.038mm

·      outlet diameter:Φ0.012-Φ0.025mm

·      max dies No.:24

·      transmission type: flat belt

·      machine type: 4capstans square type

·      max speed ( MPM/min):1800

·      Slip ratio of m/c:13.00%

·      Capstan slip ratio:8.00%

·      Control system: PLC+ men-machine interface all alarm and parameter can be controlled and displayed on a fluorescent backlid   LCD graphics screen. Digital control for motor are avaliable for computer operation.

·      Motor control: Dual inverter control

·      Capstan: Ceramic plasma

·      Capstan diameter(max) :60

·      Capstan diameter:60

·      Take-up diameter:Φ250/max

·      Bobbin loading & unloading: shaft type

·      Traversing unit: Synchronize motor type

·      Main motor:2.2KW

·      Take-up motor: 2.2KW

·      Top power consumption: 2.2KW

·      Max loading weight: 12-15kg

·      Brake: 10kg magnetic brake

·      lubrication type: spray type

·      lubrication type for bearing: without oil

·      Power: 3*380V 50/60Hz

·      Machine size: 1500*1100*1600
