Extrusion machine wire and cable machine
- 50 Set / Sets per Month
- Shanghai
- T/T
Product Details
Condition: | New | Application: | Wire | Plastic Processed: | PVC |
Screw Design: | Single-screw | Automatic Grade: | Semi-automatic | Place of Origin: | Jiangsu, China |
Brand Name: | HONTA | Model Number: | HT | Voltage: | 220V |
Power(W): | CUSTOMIZED | Dimension(L*W*H): | According to model | Weight: | BASED ON CAPACITY |
Certification: | ISO | After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
Part one Extrusion machine feayures:
- Extruder gear box adopt ground precision helical gears can gain low noise and high efficiency
- High wire running speed, stable.
- High precision of extruding production
- Handy operation. Friendly control function
- Low disorder , easy maintenance.
- All electrical accessories are all originally imported.
Part two main technical data:
Extruder main technical data | ||||||||
Machine type | HT-35 | HT-50 | HT-60 | HT-70 | HT-80 | HT-90 | HT-100 | HT120 |
Pay-off stand | Pay-off of power | Japanese type | None spindle pay-off | |||||
spool | 300-400 | 400-500
| 400-600 | 500-600 | 500-800 | 800-1000 | 1000-1260 | |
Screw dia. | φ35 | φ50 | φ60 | φ70 | φ80 | φ90 | φ100 | φ120 |
Screw lenth-dia ratio | 25/1 | |||||||
Temperature control | 6 | 7 | 7 | 8 | 8 | 10 | ||
Extrusion capacity | 50kg/h | 90kg/h | 120kg/h | 150kg/h | 180kg/h | 250kg/h | 300kg/h | 400kg/h |
Main unit power | 7.5HP | 15HP | 25HP | 30HP | 40HP | 50HP | 60HP | 75HP |
Fan no. | 3 phrases | 3 phrases | 3 phrases | 4 phrases | 4 phrases | 5 phrases | 5 phrases | 7 phrases |
Wire starage length | 250m | 250m | 250m | 250m | 250m | 250m | 300m | 300m |
Drawing power | 3HP | 3HP | 3HP | 5HP | 5HP | 7.5HP | 7.5HP | 10HP |
Taking-up type | 3HP | 5HP | 5HP | 7.5HP | 7.5HP | 10HPor 15HP | ||
Taking-up type | Pair bobbin spooling | None spindle spooling | ||||||
Taking-up speed | 600m/min | 500m/min | 500m/min | 500m/min | 400m/min | 300m/min | 250m/min |
