Plating Machine Tin Plating Machine Electrolytic Plating Line
Negotiable
MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Jiangsu, China
Brand Name:
HONTA
Model Number:
HT-10000Sn-15M/S
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Electrolytic Single Wire Plating Machine (ni/sn)NegotiableMOQ: 1 Set -
Electrolytic Plating Machine Zinc Plating Line, Plating EquipmentNegotiableMOQ: 1 Set
-
Electrolytic Plating Machine Zinc Plating Equipment 6000ANegotiableMOQ: 1 Set
-
Electrolytic Plating Machine Wire and Cable MachineNegotiableMOQ: 1 Set
-
Electrolytic Plating Machine Wire MachineNegotiableMOQ: 1 Set
Place of Origin
Jiangsu, China
Brand Name
HONTA
Model Number
HT-10000Sn-15M/S
Usage
Other, Coating, Coating & Multifunctional
Product Description
TECHNICAL DATA OF ELECTRICAL TIN PLATING MACHINE
| Machine model | HT-6000Sn-15m/s | HT-10000Sn-15m/s | HT-3000Ag-10m/s | HT-5000Ni-5m/s | HT-5000Zn-15m/s |
| Basic material | Cu | Cu,Cu-alloys | |||
| Plating material | Sn | Ag | Ni | Zn | |
| Wire Dia.(mm) | 1.00-2.60 | 1.20-2.60 | 0.90-2.60 | 0.80-2.60 | 0.80-2.60 |
| Line speed | Max 15m/s | Max 15m/s | Max 10m/s | Max 5m/s | Max 15m/s |
| Number of wires | 1 | ||||
| Coating thickness | 1-20um | 1-25um | 1-20um | 1-60um | 1-60um |
| Plating current | Max.6000A | Max.10000A | Max.3000A | Max.5000A | Max.5000A |
| Take-up type | HT-650C Down Coiler | ||||
| Pay-off type | in tandem with a drawing machine/bobbin type pay-off/basket type payoff | ||||
| Line dimension | 8000mm*6000mm*2600mm | ||||
