Electrolytic Plating Machine Wire and Cable Machine

Name: Electrolytic Plating Machine Wire and Cable Machine
Brand: HONTA
SKU: 111662283
Availability: InStock

Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)

Key Specifications

Place of Origin:

Jiangsu, China

Brand Name:

HONTA

Model Number:

HT- 5400 Ni-15 m/s

Kunshan City Hongtai Machinery & Electric Equipment Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

FOB Shanghai

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Jiangsu, China

Brand Name HONTA

Model Number HT- 5400 Ni-15 m/s

Usage Coating

Specifications

Electrolyic wire plating machine
1. Processes: degreasing; pickling; plating;
2. Applicable: Cu. wire; 13m/s;

Main technical data:

Technical Parameter of Electroplating Machine
Wire model	HT -6000-15m/s
Number of Wire	1
Line speed	Max 15 m/s
Raw material	Copper
Diameter scope	1.00 -2.6 mm ( hard wires) 1.00 -3.5 mm ( soft wires)
Requirements to the wires	low grease and without oxidation
cladding material	Sn (tin)/Ag/ Ni/Cu.
coating thickness	1 to 25 µm
coating quality	as per DIN 40500, ASTM B 33
general assembling power	approx. 120 kW
Voltage of Power	3 x 380 V, 50 Hz
control Voltage	24 V DC, 220 V AC
electrical equipment	acc. to VDE and VBG 4
Max. environmental temperature	45°C (hall temperature)
Noise level	85 dB (A) Max. 85 dB (A)
electric plating current	6000 A, 10 V
degrease electric current	500 A, 10 V
electric plating immersion length	140 m
degrease immersion length	40 m
Diameter of electric plating groove	400 mm, 27 grooves
Diameter of degrease groove	400 mm, 18 grooves
volume of collecting box	400 l
degrease	200 l
acid cleaning	200 l
electric plating	2500 l
length	About 8,000 mm
Width	About 6,000 mm
height	About 2,600 mm
Without the weight of liquid	About 8,000 kg
With the weight of liquid	About 12,000 kg

Main technical data:

Technical Parameter of Electroplating Machine
Wire model	HT -6000-15m/s
Number of Wire	1
Line speed	Max 15 m/s
Raw material	Copper
Diameter scope	1.00 -2.6 mm ( hard wires) 1.00 -3.5 mm ( soft wires)
Requirements to the wires	low grease and without oxidation
cladding material	Sn (tin)/Ag/ Ni/Cu.
coating thickness	1 to 25 µm
coating quality	as per DIN 40500, ASTM B 33
general assembling power	approx. 120 kW
Voltage of Power	3 x 380 V, 50 Hz
control Voltage	24 V DC, 220 V AC
electrical equipment	acc. to VDE and VBG 4
Max. environmental temperature	45°C (hall temperature)
Noise level	85 dB (A) Max. 85 dB (A)
electric plating current	6000 A, 10 V
degrease electric current	500 A, 10 V
electric plating immersion length	140 m
degrease immersion length	40 m
Diameter of electric plating groove	400 mm, 27 grooves
Diameter of degrease groove	400 mm, 18 grooves
volume of collecting box	400 l
degrease	200 l
acid cleaning	200 l
electric plating	2500 l
length	About 8,000 mm
Width	About 6,000 mm
height	About 2,600 mm
Without the weight of liquid	About 8,000 kg
With the weight of liquid	About 12,000 kg
