Electrolytic Tin Coating Machine Tin Plating Line

Electrolytic Tin Coating Machine Tin Plating Line thumbnail-1
Electrolytic Tin Coating Machine Tin Plating Line photo-1
Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
Place of Origin:
Jiangsu, China
Brand Name:
HONTA
Contact Supplier Request Quote Chat Now
Kunshan City Hongtai Machinery & Electric Equipment Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
SHANGHAI
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Place of Origin Jiangsu, China
Brand Name HONTA
Model Number HT-6000 Sn -15m/s
Voltage 380-430V
Certification CE
Warranty 1 year
After-sales Service Provided Engineers available to service machinery overseas
 Type of line                                                          : HT– 6000 Sn- 15 m/s

Weight without bath liquids                                : approx. 8,000 kg

Weight with bath liquids                                      : approx. 12,000 kg

Number of wires                                                  : one

Wire speed                                                           : max. 15m/s (combined with wire drawing machine or bobbin move motorised pay-off, if with coiler basket, the Max. speed is 5 m/s)

Wire material                                                       : Cu

Wire diameter range                                           : 1.2 – 3.0mm

Condition of wire                                                 : low grease and free from oxides

Coating material                                                 : Sn

Coating thickness                                               : 1 to 25 µm

Coating quality                                                    : as per DIN 40500, ASTM B 33

Total installed load                                             : approx. 120 kW

Mains voltage                                                       : 3 x 380V / 50 Hz

Control voltage                                                    : 24 V DC, 230 V AC

Electric equipment                                              : acc. to VDE and VBG 4

Max. ambient temperature                                 : 45°C (hall temperature)

Plating current                                                     : 6000 A, 10 V

Degreasing current                                             :  500 A, 10 V

Immersion length, plating                                  :  140 m

Immersion length, degreasing                          :  40 m

Groove dia. of current roller, plating                  :  400 mm, 27 grooves

Groove dia. of current roller, degreasing          :  400 mm, 18 grooves

Pictures

electrolytic tin coating machine tin plating lineelectrolytic tin coating machine tin plating lineelectrolytic tin coating machine tin plating line
