[Promotion] ( 500P / 630P / 800P / 1000P / 1250P ) ( Electric Cable Wire Making ) High-Speed Double Twist Bunching Machines
| Find More Wire Drawing Machines and Cable Making Equipment within Our Scope of Supply |
|
|
|
|
|
|
Multiwire Drawing Line Series Cu: Inlet: 1.60~2.60mm Outlet: 0.15~1.35mm Multiwire Drawing Lines *16-wire *8-wire *4-wire |
Rod Breakdown Line Series Cu: Inlet: 8.00mm Outlet: 1.20~3.50mm Copper Rod Breakdown Drawing Lines Al: Inlet: 9.50mm Outlet: 1.20~4.50mm Aluminum Rod Breakdown Drawing Lines Cu & Al: Inlet: 6.00~12.50mm Outlet: 1.00~4.50mm Individual Drive Rod Breakdown Drawing Lines
|
Intermediate Wire Drawing Line Series Cu: Inlet: 2.50~3.00mm Outlet: 0.40~1.60mm *Copper Intermediate Wire Drawing *Large-Medium Wire Drawing Al: Inlet: 2.60~4.00mm Otlet: 0.80~2.00mm *Aluminium Intermediate Wire Drawing Machine
|
Fine Wire Drawing Machine Series Cu: Inlet: 0.50~1.60mm Outlet: 0.08~0.68mm *Copper Fine Wire Drawing Machines *Fine Drawer With Annealer and Spooler *Fine Drawer With Automatic Spoolers Al: Inlet: 0.50~2.30mm Outlet: 0.15~0.70mm *Aluminum Fine Wire Drawing Machines |
Wire Coating Line Series Electroplating Lines *Sn-Tin *Ag-Silver *Ni-Nickle *Zn-Zinc Annealing & Tinning Lines |
|
|
|
|
|
|
Stranding & Bunching Series Twist Bunching Machines 500P, 630P, 800P 1000P, 1250P |
Extrusion Line Series Extrusion Lines *70/35 Extrusion Line *90/50 Extrusion Line |
Pay-Off Series Motorised Wire Pay-Off Stands
|
Take-Up Series Compact Spoolers Single Spoolers Dual Spoolers Basket Down Coilers |
Auxiliaries Cold Welders Powder Filters Threading & Pointing Machine Coil Packing Machines Spools, Bobbins, Reels
|
*
| Choose Desired Drawing Machines at a Glance - For Aluminium & Copper Wire |
*
| A Brief Glance of Our Company |
*
| Some Ways You Can Easily Find Us |
*
Product Uses
| Application of This Product |
This series of double twist bunching machines are used to twist and bunch COPPER wires of 0.25~1.00 mm dia. into cable wires of sectional area of 0.75~6.00 mm^2 high efficiently. Other cable-making machines & equipments, i.e. pay-offs, drawing machines, annealers, bunching machines, spoolers, coilers, bobbins and other auxiliaries are also available to compose a complete production line for wire cable drawing . If you have any special requirements, you are also welcome to contact us directly for customized design and manufacturing.
*
| Features of This Product |
- Magnetic powder clutch tension auto control can ensure constant tension from empty bobbin to full bobbin.
- Synchronous belt drivel mechanical pitch change; stable pitch.
- Bobbin loading and unloading is controlled by hydraulic with motor; it is easy to operate.
*
| Technical Data |
We have a series of double twist bunching machines of this kind to satisfy your diversified demands. You can always find what you prefer:
Description |
Double Twist Bunching Machine |
||||
Model No. |
HT-1000P |
HT-1250P |
HT-500P |
HT-630P |
HT-800P |
Inlet Dia. (Mm) |
0.40~1.80mm |
0.60~2.50mm |
0.08~0.45mm |
0.25~1.00mm |
0.30~1.60mm |
Bobbin Size |
1000mm |
1250mm |
500mm |
630mm |
500mm |
Sectional Area Twisted |
6.00~25.00mm^2 |
10.00~50.00mm^2 |
0.50~2.50mm^2 |
0.75~6.00mm^2 |
2.50~16.00mm^2 |
Twisting Pitch |
35~200mm |
35~300mm |
4.22~39.64mm |
11.15~100mm |
17~200mm |
Main Motor Power |
22kW AC |
37kW AC |
7.5kW AC |
11kW AC |
18.5kW AC |
Max. Rotation Speed |
1000rpm |
800rpm |
2200rpm |
1800rpm |
1200rpm |
Tension Control Method |
Magnetic powder clutch automatic adjustment |
||||
Traverse Type |
Bare rod traverse with adjustable displacement distance |
||||
Wire Break Inspection |
Digital display, machine auto-stop if wire break |
||||
Twist Direction |
S or Z direction |
||||
Power Supply
^ 3-phase voltage ~3×380VAC (±10%)
^ Single-phase voltage ~220VAC (±10%)
^ Frequency 50Hz (±2%)
Note: This is an important factor affecting price. If the power supply in your country or region is different from our system, please advise us in your inquiry.*
