Double Twist Bunching Machine With Double Motorised Pay-off Wire Twisting Machine Pay-off Machine

Double Twist Bunching Machine With Double Motorised Pay-off Wire Twisting Machine Pay-off Machine thumbnail-1
Double Twist Bunching Machine With Double Motorised Pay-off Wire Twisting Machine Pay-off Machine photo-1
Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Jiangsu, China
Brand Name:
HONTA
Model Number:
HT-650P
Contact Supplier Request Quote Chat Now
Kunshan City Hongtai Machinery & Electric Equipment Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Jiangsu, China
Brand Name HONTA
Model Number HT-650P
Usage Twisting

Double Twist Bunching Machine with Double Motorised Pay-off wire twisting machine pay-off machineDouble Twist Bunching Machine with Double Motorised Pay-off wire twisting machine pay-off machine

Double Twist Bunching Machine with Double Motorised Pay-off

Model: HT-650P

Structure: our double twist bunching machine consists of two main parts, the pay-off part and the main machine.

Technical data



Wire diameter                                                : φ 0.10mm –φ0.68mm,

Stranding sectional area                                    : 0.05-6.0mm2

Take up bobbin                                             : PND 630

Rotational speed                                           : Max. 2000rpm/4000TPM

Drive                                                              : 11KW AC

Stranding pitches                                           : 11.15- 100.00mm

Pitch change                                                  : Manually change pulling capstans

Bobbins loading and unloading                     : by hydraulic with motor

Traverse                                                        : polish rod traverse with adjustable width and distance.

Noise level                                                     : ≤ 85dB(A)

Center height                                                 : 750mm

Stranding direction                                        : leftward or rightward (S or Z)

Outside measurement (main machine)         : approx. 2770X1480X1540

Weight                                                           : about 3500KG

Pictures

Double Twist Bunching Machine with Double Motorised Pay-off wire twisting machine pay-off machineDouble Twist Bunching Machine with Double Motorised Pay-off wire twisting machine pay-off machineDouble Twist Bunching Machine with Double Motorised Pay-off wire twisting machine pay-off machine

Certification

Double Twist Bunching Machine with Double Motorised Pay-off wire twisting machine pay-off machine

Please contact us for more information.

Double Twist Bunching Machine with Double Motorised Pay-off wire twisting machine pay-off machine
