Standard Cylinder
US$ 20 - 68
MOQ: 200 Pieces
Key Specifications
Get Latest Price
Material:
Steel
Use:
Oxygen
Pressure:
High
Payment & Shipping
Payment Methods:
Port of Shipment:
Tianjin
Delivery Detail:
Delivery time depends on order quantity.
Related Products
Material
Steel
Use
Oxygen
Pressure
High
Place of Origin
Hebei, China
Brand Name
ZP
Specifications
standard cylinder1. O.D. : 140/152/219mm
2. Capacity: 4-40L
3. WP: 15MPa/150BAR
4. Stanard: GB5099
standard cylinder
The standard cylinder are all made of high quality steel, and are supposed to be used repeatedly for keeping oxygen. It can be used in industry, agriculture, medical treatment, scientific research and analytical instruments etc..
Detailed specification
| No. | Outside diameter | Capacity | Gas capacity | Design | Length | Weight | WP | TP | Material |
| MM | V(L) | (M3) | Wall thickness | Approx L | Approx W | MPa | MPa | ||
| S(MM) | (MM) | (Kg) | |||||||
| 1 | 140 | 2.5 | 0.37 | 3.6 | 390 | 7 | 15 | 25 | 37Mn |
| 3.2 | 0.48 | 440 | 7.5 | ||||||
| 4.0 | 0.60 | 500 | 8.3 | ||||||
| 5.0 | 0.75 | 575 | 9.3 | ||||||
| 6.3 | 0.94 | 670 | 10.6 | ||||||
| 7.0 | 1.05 | 720 | 11.3 | ||||||
| 8.0 | 1.20 | 795 | 12.3 | ||||||
| 9.0 | 1.35 | 870 | 13.3 | ||||||
| 10.0 | 1.50 | 945 | 14.3 | ||||||
| 2 | 152 | 7 | 1.1 | 4 | 635 | 12 | 15 | 25 | 37Mn |
| 8 | 1.2 | 700 | 13 | ||||||
| 9 | 1.4 | 760 | 14 | ||||||
| 10 | 1.5 | 825 | 15 | ||||||
| 12 | 1.8 | 850 | 17 | ||||||
| 3 | 219 | 20 | 3.0 | 5.7 | 850 | 31.3 | 15 | 25 | 37Mn |
| 25 | 3.7 | 1000 | 36.4 | ||||||
| 32 | 4.8 | 1210 | 43.6 | ||||||
| 34 | 5.1 | 1270 | 45.6 | ||||||
| 36 | 5.4 | 1330 | 47.7 | ||||||
| 38 | 5.7 | 1390 | 49.7 | ||||||
| 40 | 6.0 | 1450 | 51.7 | ||||||
| 45 | 6.7 | 1600 | 56.8 |
Product Picture
Send Inquiry to This Supplier
Business Type
Manufacturer, Trading Company
Year Established
2001
Factory Size
1,000-3,000 square meters
Total Employees
501 - 1000 People
