OV5640 OV5645 OV5647 OV5648 OV5650 OV5653 OV5656 OV5658 OV5670 OV5680 OV5682 OV5630 Camera Module
Negotiable
MOQ: 1 Piece (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Hong Kong, China
Brand Name:
KLT
Model Number:
JAL-GC2235-A128F
Payment & Shipping
Payment Methods:
Port of Shipment:
Hong Kong
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
OV10823 OV8825 OV8860 OV8858 OV8865 OV5640 OV5645 OV5648 OV5658 OV5670NegotiableMOQ: 1 Piece -
OV16825 OV16850 OV16880 OV13860 OV13853 OV13850 OV10823 VO8865 OV8858 OV8840 OV8870 Camera ModuleNegotiableMOQ: 1 Piece
-
OEM COB CCTV OV9715 OV9714 OV9712-1D OV10642 OV10640 OV10635 OV10633 OV10630 OV10650 Camera ModuleNegotiableMOQ: 1 Piece
-
OmniVision OV2710 MIPI Interface Fixed Focus 2MP Camera Module JAL-KR6-OV2710 V1.0NegotiableMOQ: 1 Piece
-
OEM COB CCTV OV9715 OV9714 OV9712-1D OV10642 OV10640 OV10635 OV10633 OV10630 OV10650 Camera ModuleNegotiableMOQ: 1 Piece
Place of Origin
Hong Kong, China
Brand Name
KLT
Model Number
JAL-GC2235-A128F
Type
Other, Digital Camera, CMOS Camera
Style
Other, Flex Cable Type
Sensor
CMOS
Technology
Pinhole
JAL-GC2235-A128F
GalaxyCore GC2235 MIPI Interface Fixed Focus 2MP Camera Module
| Camera Module No. | JAL-GC2235-A128F |
| Image Sensor | GC2235 |
| EFL | 2.7 mm |
| F.NO | 2.8 |
| Pixel | 1600 x 1200 (UXGA) |
| View Angle | 64° |
| Lens Type | 1/5 inch |
| Lens Dimensions | 6.5 x 6.5 x 4.6 mm |
| Module Size | 14.45 x 8.5 mm |
| Module Type | Fixed Focus |
| Interface | MIPI |
| Mating Connector | 24-5804-024-000-829 |
| Pin No. | Pin Layout Description |
| 1 | AF_GND |
| 2 | VAF_2.8 |
| 3 | VCAMD_1.8V |
| 4 | VCAMIO_1.8V |
| 5 | NC |
| 6 | AGND |
| 7 | AVDD |
| 8 | DGND |
| 9 | I2C_SDA |
| 10 | I2C_SCL |
| 11 | RESET |
| 12 | PWDN |
| 13 | GND |
| 14 | MCLK |
| 15 | GND |
| 16 | MIPI_DP1 |
| 17 | MIPI_DN1 |
| 18 | GND |
| 19 | MIPI_CP |
| 20 | MIPI_CN |
| 21 | GND |
| 22 | MIPI_DP0 |
| 23 | MIPI_DN0 |
| 24 | GND |
1/5” UXGA CMOS Image Sensor
GC2235 is a high quality 2Mega CMOS
image sensor, for mobile phone camera
applications and digital camera products.
GC2235 incorporates a 1616V x 1232H pixel
array, on-chip 10-bit ADC, and image signal
processor.
The full scale integration of
high-performance and low-power functions
makes the GC2235 best fit the design, reduce
implementation process, and extend the
battery life of cell phones, PDAs, and a wide
variety of mobile applications.
It provides RAW10 and RAW8 data
formats with MIPI interface. It has a
commonly used two-wire serial interface for
host to control the operation of the whole
sensor.
