ISP DSP HDR 3D DSC DVC EIS DPCM Full HD VGA OV6211 OV7221 OV7251 OV7675 OV7676 OV7695 Camera Module
Negotiable
MOQ: 1 Piece (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Brand Name:
KLT
Model Number:
JAL-KH2-K4700F
Type:
Fixed Focus Lens
Payment & Shipping
Payment Methods:
Port of Shipment:
Hong Kong
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
OVM9724 OVM7692 OVM7695 OVM7699 OV480-B81G-Z OV62-B64 OV530-B49 OV530-T64 OV538-B88 Camera ModuleNegotiableMOQ: 1 Piece -
OV550-B49 OV560-B100 720p USB OV2724 OV3660 VO3640 OV4682 RBG IR OV4688 No IR OV8865 Camera ModuleNegotiableMOQ: 1 Piece
-
OV23850 OV21840 OV16825 OV16850 OV16880 OV13850 OV13853 OV13860 OV8830 OV8835 OV8810 Camera ModuleNegotiableMOQ: 1 Piece
-
OV5640 OV5645 OV5647 OV5648 OV5650 OV5653 OV5656 OV5658 OV5670 OV5680 OV5682 OV5630 Camera ModuleNegotiableMOQ: 1 Piece
-
OV10823 OV8825 OV8860 OV8858 OV8865 OV5640 OV5645 OV5648 OV5658 OV5670NegotiableMOQ: 1 Piece
Brand Name
KLT
Model Number
JAL-KH2-K4700F
Type
Fixed Focus Lens
Place of Origin
China
Compatible Brand
Canon, Casio, Fujitsu, Nikon, Pentax, Samsung, Sigma, Other, Other, Canon, Casio, Fujitsu, Nikon, Pentax, Samsung, Sigma, Sony, Minolta, Other
JAL-KH2-K4700F
Hynix HI-253 Parallel Interface Fixed Focus 2MP Camera Module
| Camera Module No. | JAL-KH2-K4700F |
| Image Sensor | HI-253 |
| EFL | 2.37 mm |
| F.NO | 2.2 |
| Pixel | 1600 x 1200 (UXGA) |
| View Angle | 60° |
| Lens Type | 1/5 inch |
| Lens Dimensions | 6 x 6 x 4 mm |
| Module Size | 14.3 x 7.59 mm |
| Module Type | Fixed Focus |
| Interface | Parallel |
| Mating Connector | AXK7L24227 |
| Pin No. | Pin Layout Description |
| 1 | NC |
| 2 | GND |
| 3 | SIO_D |
| 4 | AVDD (2.8V) |
| 5 | SIO_C |
| 6 | RESET |
| 7 | VSYNC |
| 8 | PWDN |
| 9 | HREF |
| 10 | DVDD (1.2V) |
| 11 | DOVDD (1.8V) |
| 12 | Y7 |
| 13 | XCLK |
| 14 | Y6 |
| 15 | GND |
| 16 | Y5 |
| 17 | PCLK |
| 18 | Y4 |
| 19 | Y0 |
| 20 | Y3 |
| 21 | Y1 |
| 22 | Y2 |
| 23 | NC |
| 24 | NC |
