WAW-300DJ SERVO UNIVERSAL TESTING MACHINE
Negotiable
MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Zhejiang, China
Brand Name:
jingyuan
Model Number:
WAW-300DJ
Payment & Shipping
Payment Methods:
Port of Shipment:
NingBo
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
WE-1000p Computer Display Hydraulic Universal Testing MachineNegotiableMOQ: 1 Set -
WE-1000P Computer Display Hydraulic Universal Testing Machine UTMNegotiableMOQ: 1 Set
-
WES-600B LCD HYDRAULIC UNIVERSAL MATERIAL TESTING MACHINE 6 COLUMNSNegotiableMOQ: 1 Set
-
WAW 600-1000KN Servo Hydraulic Steel Strand Material Testing MachineNegotiableMOQ: 1 Set
-
WES 2000kn LCD UNIVERSAL TENSILE TESTING MACHINE (6 COLUMNS)NegotiableMOQ: 1 Set
Place of Origin
Zhejiang, China
Brand Name
jingyuan
Model Number
WAW-300DJ
Power
Hydraulic
Usage
Universal Testing Machine
Specifications
Tensile compressionflexure shear peel tear and
other tests of nonmetallic
materials with servo valve control
Single test
WAW-300DJ SERVO UNIVERSAL TESTING MACHINE
Product Description
Capacity: 300kN-2000KN
Application: Tensile compression flexure shear peel tear and other tests of nonmetallic materials with servo valve control. Single test space, hydraulic side action grips
Mode |
WAW-300DJ |
WAW-600DJ |
WAW-1000DJ |
WAW-2000DJ |
Max capacity(KN) |
300 |
600 |
1000 |
2000 |
Accuracy |
Class 0.5/1 |
|||
Load range |
1%-100%FS |
|||
Extension measurement range |
1%-100%FS |
|||
Extension measurement accuracy |
Within ±1%/±0.5% |
|||
Extension measurement resolution |
1/300000 of Max. extension |
|||
Loading speed range |
0.02%-2%FS/s |
|||
Piston stroke up range |
0-350mm/min |
0-350mm/min |
0-350mm/min |
0-300mm/min |
Piston stroke down range |
0-200mm/min |
0-200mm/min |
0-550mm/min |
0-600mm/min |
Max tensile space(mm) |
550 |
580 |
720 |
780 |
Max compression space(mm) |
420 |
460 |
520 |
520 |
Round specimen diameter(mm) |
Φ10-Φ40 |
Φ10-Φ45 |
Φ15-Φ60 |
Φ15-Φ100 |
Flat specimen thickness(mm) |
2-40 |
2-45 |
2-60 |
2-80 |
Compression platen(mm) |
Φ120 |
Φ150 |
200X200 |
Φ240 |
Piston Stroke(mm) |
520 |
560 |
650 |
750 |
Main frame dimension(mm) |
850X400X2700 |
850X400X2900 |
9800X720X3540 |
1220X880X4200 |
Oil station dimension(mm) |
950X550X110 |
950X550X1100 |
1500X650X1250 |
1500X700X1250 |
Power supply(kW) |
5 |
7 |
15 |
18 |
Weight(kg) |
2000 |
2500 |
6500 |
10000 |
