Specifications
Mainly used in railwayroads bridges ports
high-rise building construction on the concrete
components pipe
hydraulic jack
YES-2000B digital compression testing machine
YES-2000B Type Digital Pressure Test Machine
The main uses and characteristics:
Mainly used in railway, roads, bridges, ports, high-rise building construction on the concrete, components, pipe, hydraulic jack, building materials such as compressive strength tests, can also be used for metal and other non-metallic materials, the compressive strength of test components . This machine adopts electric lift on the platen to ease adjustment test room, using sensors measuring, display real-time display force value, loading speed, and intuitive readings, high precision (a precision of national standards) may have a loading number query speed tracking, super-range protection, real-time display, print and other functions, leaving communication interface and the user data local area network connecting the remote output, is a highly cost-effective testing machine.
Model Specification
YES-2000B Maximum Test Force (KN) 2000 Measuring range (FS) 4% ~ 100% (according to user requirement was raised to 1% ~ 100%) Showing the value of the maximum allowable value of relative error ± 1.0% Acceleration error maximum allowable value +5% Test Space The upper and lower platen size (mm) 240 × 240 The upper and lower platen maximum distance (mm) 330 Column spacing (mm) 320 × 220 Working Piston Stroke (mm) 60
