Specifications
YAW-2000compression testing machine
Series Microcomputer
Controlled Electro- Hydraulic
Servo Compression Testing
digital display computer control concrete compression testing machine
Applications and Characteristic: this series is mainly designed for compression test of concrete, components tubular pile, hydrostatic and building materials in railway, highway, bridge, port, high building and other projects, as well as of metallic & non-metallic materials. With PC-electro-hydraulic servo control system, it can complete auto-control loading with unchanged speed and realize constant test stroke holding. It can also realize cycling loading and unloading process (according to corresponding test requirement), display test load and the curves of test load time on screen, and store them for further check. Testing report can be finished automatically, and be printed out with network joint set aside. The product can adjust test space like a cork by using electric lift for platen. Its powerful functions can satisfy most user requirements.
digital display computer control concrete compression testing machine
model |
YAW-2000 |
|||
(KN)maximum test force |
2000 |
|||
(FS)measuring range |
4%-100% we can improve range to 1% -100% |
|||
maximum magnitude for relative error of indicating value |
±1.0% |
|||
(KN/S) rang of loading speed |
1.0~9.9 |
|||
maximum permissible value of acceleration error |
±5% |
|||
testing space |
(mm) upper and lower plate dimensions |
Φ-300(upper)Φ400 (lower) |
||
(mm) maximum distance of upper and lower plate |
380 |
|||
(mm) distance between upright |
420 x420 |
|||
(mm)working Piston Travel |
100 |
|||
structure feature |
upper beam elevate when being electrified |
upper beam elevate when being electrified. lower plate can be moved out |
||
(kW) motor power |
2 |
|||
(mm) external dimension(L×W×H) |
main body |
850 x 850 x 1750 |
||
control box |
620 x 480 x 1135 |
|||
(kg) net weight |
2000 |
|||
