Specifications
Individual color purging minmizes the waste of the ink.3 way intelligent heater helps bring more vivid output.
Infiniti/Challenger Solvent Printer FY-3208H/3206H/3204H:
Equipment of SPT 510/35pl Piezo print head which comes with 510 nozzles, 71.8mm of printing width, and 720dpi printing resolution enable the printer achieve ideal printing quality and color.
1, The print head voltage is able to adjust automatically depending on the temperature, this will solve the problem on nozzle clogging under huge temperature change.
2, The function of skipping white space is added to increase productivity.
3, The adjustment of bi-direction, step and carriage moving speed can be modified during printing.
4, Edge feather function can blur the pass line and feather pass edge.
5, Well designed alloy-aluminum girder is installed to decrease the noise during printing, Achieve perfect quiet working environment.
6, Photoprint / Maintop / Wasatch software provide user-friendly interface and handy function with two types of printing.
7, 100% single color black is used on printing black text to avoid mixture of color.
8, Control system has the function of resuming printing after the power is cut off. This helps to save unnecessary loss of cost.
9, The powerful suction fans equipped under the printing platform to avoid the collision between the carriage and the media, high resolution can be obtained.
| Model | FY-3204H | FY-3206H | FY-3208H | |
| Print Head | Type | Spt 510 – 35pl | ||
| Quantity | 4 | 6 | 4 * 2 | |
| Resolution (dpi) | 1080 | |||
| Color | 4 color | 6 color | 4 color | |
| Speed | 3 pass 240*540dpi | 54.9m2/hr | 54.9m2/hr | 76m2/hr |
| 4 pass 240*720dpi | 44.3m2/hr | 44.3m2/hr | 60m2/hr | |
| 6 pass 360*1080dpi | 21.3m2/hr | 21.3m2/hr | 34m2/hr | |
| Media | Width | Max 3300mm (129.92’ ) | ||
| Type | Frontlit, Backlit, Vinyl, Polyester, Window Film, Mesh, Leather, Backlit Film, etc | |||
| Weight | Max 80kgs | |||
| Thickness | Max 4mm | |||
| Feeding and Take-up | Equipped | |||
| Cleaning System | Positive Pressure Cleaning, Anti-Clogging Flash Function & Capping System | |||
| Heating System | Pre/Post Heater, Cooling Fan System | |||
| Working Environment | Temperature: 20C-28C; Humidity: 40%-60% | |||
| Rip Software | Photoprint, Maintop, Wasatch (optional) | |||
| Print Head Height | 2-4mm (adjustable) | |||
| Interface | USB | |||
| Power | AC220V, 50HZ/60HZ, Printing 660W, Heater 1450W | |||
| Dimension (mm) | Machine | L4520*W860*H1340 398KGS± 15KGS | ||
| Packing | L4630*W880*H1050 450KGS± 15KGS | |||
