Crystaljet 3.2m CJ4000 Series Large Format Solvent Printer With Spt 35pl/50pl Head
US$ 9,500 - 15,500
MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Plate Type:
Gravure
Place of Origin:
Guangdong, China
Payment & Shipping
Payment Methods:
Port of Shipment:
Guangzhou
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Infinity Brand FY3278N 3.2m Wide Format Solvent PrinterUS$ 9,000 - 15,500MOQ: 1 Set -
3.2m Large Format Solvent Printer FY Union Infiniti Fy3278 Printer With Spt HeadsUS$ 9,000 - 15,500MOQ: 1 Set
-
3.2m Challenger FY-3278n Large Format PrinterUS$ 9,000 - 15,500MOQ: 1 Set
-
Infinity FY-3278N Solvent Printer/ Challenger Printing MachineUS$ 9,000 - 15,500MOQ: 1 Set
-
Large Format Printer CJ 4000 With Spt HeadUS$ 10,000 - 13,000MOQ: 1 Set
Condition
New
Plate Type
Gravure
Place of Origin
Guangdong, China
Brand Name
Crystaljet CJ4000
Model Number
Crystaljet 3.2m CJ4000 Series Large Format Solvent Printer
Usage
Other, solvent printer
Automatic Grade
Automatic
Voltage
220v 50/60HZ
Gross Power
220v 50/60HZ
Dimensions(L*W*H)
4840mm(L)X1000mm(W)X1340mm(H)
Weight
520 KG
Certification
CE
After-sales Service Provided
Engineers available to service machinery overseas
3.2m Crystaljet CJ4000 flex banner solvent printer/seiko head printer
lvent printer
2. Max print width:126.0" (3200mm)
3 .Print head:SPT510_35PL
4. Printer Resolution:720dpi
5. MOQ:1set
| Model | S4306SPT510_35PL | F4308SPT510_35PL | F4304SPT510_50PL | F4308SPT510_50PL | ||
| Printhead | SPT510_35PL | SPT510_50PL | ||||
| No of Printheads | 6 | 8 | 4 | 8 | ||
| Printhead combination | 1×6 | 2×4 | 1×4 | 2×4 | ||
| Print Width | 3200mm 125.98inch | |||||
| Media Width | 3220mm 126.77inch | |||||
| Print speed | Print mode | speed | speed | speed | speed | |
| High speed | 240X540 3pass 56m²/hr | 240X540 3pass 112m²/hr | 240X540 3pass 65m²/hr | 240X540 3pass 130m²/hr | ||
| Middle speed | 240X720 4pass 41m²/hr | 240X720 4pass 82m²/hr | 240X540 3pass 51m²/hr | 240X540 3pass 102m²/hr | ||
| Standard speed | 360X540 3pass 37m²/hr | 360X540 3pass 74m²/hr | 180X720 4pass 47m²/hr | 180X720 4pass 94m²/hr | ||
| Ink Type | Ink Type | Solvent Ink | ||||
| Color | KCMYLcLm | KCMY | KCMY | KCMY | ||
| Ink supply system | Automatic ink suppy based on auto-detected ink level, failure alarming, empty main tank prompt(optional) | |||||
| Cleaning method | Singel color positive flush(with pressure protection), auto flushing & head moisturizing | |||||
| RIP software | MainTop( Photoprint optional) | |||||
| Interface | USB2.0 | |||||
| Printing assistant system | Auto feeding system | Infrared-detecting, feed & take-up system with memory function | ||||
| Heating system | Three stage heating system(Preheating, Print- heating, post- heating) | |||||
| Head heating | Low-voltage consistant-temperature head-heating(DC24V) | |||||
| Height of the tray | 2~5mm Distance to platform, adjustable | |||||
| Other functions | One key positive-pressure ink injecting,adjustable force of media being absopted to platform, anti-warp media-press,subtank heater(optional),lighting for head cleaning, drying fan, anti-splash board, emergency stop, full waste tank prompt | |||||
| Printer info | Voltage | AC220V 50/60HZ (AC110V 50/60HZ is optional) | ||||
| Power | Printing system 500W Heating system(Post-,1000w, print-,1500w, pre-, 1000w) | |||||
| Working environment | Normal temperature 22~28°C Himidity 40%~70%RH | |||||
| Machine size and weight | 4840mm(L)X1000mm(W)X1340mm(H) 520kg±15kg | |||||
| Shipping size and weight | 5230mm(L)X1040mm(W)X1480mm(H) 740kg±15kg | |||||
