3.2m Large Format Solvent Printer FY Union Infiniti Fy3278 Printer With Spt Heads

Name: 3.2m Large Format Solvent Printer FY Union Infiniti Fy3278 Printer With Spt Heads
Brand: INFINITI
SKU: 111557783

US$ 9,000 - 15,500 MOQ: 1 Set

Key Specifications

Condition:

New

Plate Type:

Other, solvent printer

Place of Origin:

Guangdong, China

Guangzhou Crystek Electronic Equipment Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Huangpu

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Plate Type Other, solvent printer

Place of Origin Guangdong, China

Brand Name INFINITI

Model Number FY-3278N

Usage Other, solvent printer

Automatic Grade Automatic

Voltage AC 220V/230V 50Hz/60Hz

Gross Power 660W

Dimensions(L*W*H) 4600mm X 820mm X 1320mm

Weight 570kg± 15kg

Certification CE

After-sales Service Provided Engineers available to service machinery overseas

3.2m large format solvent printer INFINITI FY-3278N

4 / 8 Seiko SPT510 print head

♥ Double 4 color printing,the standard output achieves 157m²/hr.

♥ AC servo motor is used to run the carriage quicker and more stable.

♥ Individual color purging minmizes the waste of the ink.

♥ 3 way intelligent heater helps bring more vivid output.

♥ The entire printing platform and the girder are made of the alloy-aluminum which is more strong and flat.

♥ Adopt USB2.0 output system,faster and more flexible.

Model	FY-3278N
Print Head	Drop on demand Piezo Head (SPT510-50PL)
Number of Print Head	8 Heads
Maximum Print Width	3, 200mm(125.98” )
Print Speed	Draft	2 Pass 157m 2 / hr
	Standard	3 Pass 109m 2 / hr
	Quality	3 Pass 91m 2 / hr
	High Quality	4 Pass 70m 2 / hr
Max. Media Width	3, 300mm(129.92' )
Max. Media Weight	80kg
Media Type	Frontlit, Backlit, Vinyl, Polyester, Window Film, Mesh, Leather, Backlit Film, Blue Back Paper…
Media Thickness	4mm(Max. )
Heating System	3 way intelligent heater
Auto Media Feeding & Take-up System	Equipped
Ink	Solvent Ink (C M Y K)
Auto Cleaning System	Positive Pressure Cleaning, Anti-Clogging Flash Function & Capping System
Print Interface	USB 2.0
Power Specification	AC 220V/230V 50Hz/60Hz; Printing: 660W
	Heater: 6900W
Operational Environment	Temperature: 20° C-28° C Humidity: 40%-60%
Compatible RIP Software	Photoprint, UltraPrint, Topaz, Wasatch, Caldera, Maintop
Machine size	L4600mm X W820mm X H1320mm 570kg± 15kg
Package size	L4750mm X W970mm X H1580mm 770kg± 15kg
