smt pick and place machine High universal Placement KT200
- 20 Piece / Pieces per Month
- Tianjin / shanghai / ningbo /Qingdao
- T/T Credit Card
- Low Cost 2D Electronic Compass
- XCG series circular connector plug socket XCG39T62Z1P3(X) XCG39F62K1D3(X)
- MS series circular connector plug socket MS3116F16-26P MS3116F16-26S
- MS series circular connector plug socket MS3116F14-19P MS3116F14-19S
- MS series circular connector plug socket MS3116F12-10S MS3116F12-10P
- MS series circular connector plug socket MS3116F10-6P MS3116F10-6S
Product Details
Place of Origin: | Beijing, China | Brand Name: | HVT | Model Number: | KT200 |
Product Description
Specification of High speed universal Placement KT200
Max PCB size | 400mm*305mm |
Max moving range of Z axis | 20mm |
Max mounting speed | 5000cph |
Average mounting speed | 4500cph |
Minimum moving distance | 0.01mm |
Position accuracy | 0.1mm |
Mounting heads | 2 |
Feeder qty | 48 pcs(8mm) |
Components | 0402,0603,0805,1206(3014),1210(3528),5050,SOT, |
Motion drive system | high speed DSP digital high voltage drive |
TComponent angle rotation | 0-360 degree angle, the movement of synchronous rotation |
Vacuum source | vacuum generator, vacuum pump |
Operation system | windows xp |
Power | 220V, 50Hz |
Dimension | 945mm×800mm×1450mm |
If you only samll production demand and budget cost is not too much , this kind of machine very better for you .
Application field : IGBT modular , MEMS packaging, Large-power component ,LED light
Product features:
1. High performance double mounting heads machine, the most suitable for large quantities of RC and SOP mixed production
2 . Configured with different feeders can meet the requirement of different components mounting.
3. Head drive uses a stepper motor with high precision guide, makes the discharge more stable and fast.
4 . High precision and high speed servo motor drive is used to drive the industrial belt, which can effectively improve the precision of the chip and the speed of the circuit board.
5. The allocation of proprietary architectures have 2 groups of heads, flexible structure, overall head weight is less than 800g, make the operation more quickly.
6. Special heat sink design can make the equipment work continuously.
7. The whole machine is controlled by the industrial computer with special software, which is convenient and practical .
8. The automatic Visual online programming software, without manual input element coordinates, programming is simple, easy for beginners to convenient and practical, meet mass production of a variety of demand. To carry out a simple setting, you can achieve PCB fight board programming and paste.
9. PCB import to achieve convenient, fast, reduce the programming time.
10 . Open set method, the intelligent optimization based on artificial optimization becomes possible, improve production efficiency .
11 . Unique electrical system design, easy to heat, maintenance and system maintenance.
12 . The unique x three axis design, make the head more stable, more accurate. Y axis linkage rod by avoiding design, make the rear access feeder is more convenient.
13. You can display all the coordinates of the board in the software, and the coordinates of the fine-tuning, to achieve high precision.
14 . You can set the distance between each puzzle in software, and depending on the spacing shows all material coordinates, you can choose not to stick the imposition.
15 .With the lack of material monitoring function and manual mounting function, to meet different production requirements .
16 . Optional mirror system, so that the key parts of the paste is more accurate.
17. According to the components of the situation to choose whether or not to deal with, improve the use of the actual loading speed.
18 . According to the customer's requirements, select the compressed air and vacuum pump to provide a vacuum, make full use of customer resources, reduce one-time investment and live long.
Packaging & Shipping:
Our service :
Why you choose us ?
1 . Face to face technical guidance : our professional technical staff will be abroad for technical guide and after-sale service .
2. Visual monitoring analysis system: Real -time monitoring the welding process and perform statistical analysis on date . stability , reliability and security operating system .
3. Rapid cooling system : Independent water cooling and gas cooling device is set in the cavity, achieve rapid cooling of the device.
Office and workshop show :
FAQ :
Question:Which payment terms you will accept?
Answer : L/C, T/T, West Union.paypal
Question: What is your delivery time?
Answer: For some normal standard size furnaces and components, we have in stock of semi-finished products ; So we can send out in 10 days; Others the delivery time is from 15 days to 45 days according to different products request.
Question: What logistic shipping ways you can send the products?
Answer: We can send goods out by sea, by air or by express per customer's requirement.
Question: What about your after-sale service?
Answer: Our warranty time is one year for defects in materials or workmanship. During this period, we will replace the bad components free of charge for customers,but this warranty does not cover consumables and failures because of abusing, misusing, accident or unauthorized alteration or repairing. Heating element is not included inside.
