Help CenterHigh Precision SMT Chip Mounter SMT Low Cost Pcb Machine
Related Products
-
Smd Led Mounting MachineUS$ 20,000 - 30,000MOQ: 1 Piece -
Led Tube Strip Panel Lamp Production Led Lamp Manufacturing MachineryUS$ 20,000 - 30,000MOQ: 1 Piece
-
Led Pick and Place Machine 4 Heads High Speed Placing Chip MounterUS$ 50,000 - 60,000MOQ: 1 Piece
-
Good Quality Desktop Smt Chip MounterUS$ 50,000 - 60,000MOQ: 1 Piece
-
High Quality LED Chip Mounter Made in ChinaUS$ 50,000 - 60,000MOQ: 1 Piece
Specification of High speed universal Placement KT200
| Max PCB size | 400mm*305mm |
| Max moving range of Z axis | 20mm |
| Max mounting speed | 5000cph |
| Average mounting speed | 4500cph |
| Minimum moving distance | 0.01mm |
| Position accuracy | 0.1mm |
| Mounting heads | 2 |
| Feeder qty | 48 pcs(8mm) |
| Components | 0402,0603,0805,1206(3014),1210(3528),5050,SOT, |
| Motion drive system | high speed DSP digital high voltage drive |
| TComponent angle rotation | 0-360 degree angle, the movement of synchronous rotation |
| Vacuum source | vacuum generator, vacuum pump |
| Operation system | windows xp |
| Power | 220V, 50Hz |
| Dimension | 945mm×800mm×1450mm |
If you only samll production demand and budget cost is not too much , this kind of machine very better for you .
Application field : IGBT modular , MEMS packaging, Large-power component ,LED light
Product features:
1. High performance double mounting heads machine, the most suitable for large quantities of RC and SOP mixed production ,Configured with different feeders can meet the requirement of different components mounting.
2. Head drive uses a stepper motor with high precision guide, makes the discharge more stable and fast.
3. High precision and high speed servo motor drive is used to drive the industrial belt, which can effectively improve the precision of the chip and the speed of the circuit board.
4. The whole machine is controlled by the industrial computer with special software, which is convenient and practical , Special heat sink design can make the equipment work continuously.
5. The automatic Visual online programming software, without manual input element coordinates, programming is simple, easy for beginners to convenient and practical, meet mass production of a variety of demand. To carry out a simple setting, you can achieve PCB fight board programming and paste.
6. Unique electrical system design, PCB import to achieve convenient, fast, reduce the programming time.
7 . The unique x three axis design, make the head more stable, more accurate. Y axis linkage rod by avoiding design, make the rear access feeder is more convenient.
8 . You can set the distance between each puzzle in software, and depending on the spacing shows all material coordinates, you can choose not to stick the imposition.
9.With the lack of material monitoring function and manual mounting function, to meet different production requirements . the compressed air and vacuum pump can choose by yourself .
Packaging & Shipping:
Our service :
Why you choose us ?
1 . Face to face technical guidance : our professional technical staff will be abroad for technical guide and after-sale service .
2. Visual monitoring analysis system: Real -time monitoring the welding process and perform statistical analysis on date . stability , reliability and security operating system .
3. Rapid cooling system : Independent water cooling and gas cooling device is set in the cavity, achieve rapid cooling of the device.
Office and workshop show :
FAQ :
Question:Which payment terms you will accept?
Answer : L/C, T/T, West Union.paypal
Question: What is your delivery time?
Answer: For some normal standard size furnaces and components, we have in stock of semi-finished products ; So we can send out in 10 days; Others the delivery time is from 15 days to 45 days according to different products request.
Question: What logistic shipping ways you can send the products?
Answer: We can send goods out by sea, by air or by express per customer's requirement.
Question: What about your after-sale service?
Answer: Our warranty time is one year for defects in materials or workmanship. During this period, we will replace the bad components free of charge for customers,but this warranty does not cover consumables and failures because of abusing, misusing, accident or unauthorized alteration or repairing. Heating element is not included inside.
