Specification of Full automatic visual placement KT3050 :
| Max PCB size | 400 mm×305 mm |
| Max moving range of Z axis | 20mm |
| Z axis motor | Two mounting heads are controlled by two motors respectively |
| Theoretical mounting speed | 6000cph |
| Max mounting speed | 5000cph |
| Min moving distance | 0.01mm |
| Positioning accuracy | 0.1mm |
| Mounting heads qty | 2 |
| Feeder qty | 50pcs(8mm) |
| Components range |
0402,0603,0805,1206(3014),1210(3528) ,5050,SOT,SOIC,QFP,QFN |
| Motion drive system | High speed DSP digital high pressure drive |
| Belt feeder | 8mm 12mm 16mm 24mm 32mm44mm |
| Vacuum source | Vacuum generation Vacuum pump is optional |
| Operation system | windows xp,sp3 |
| Programming way | Industrial computer visual programming, PCB file coordinate import. |
| Power source | 220V, 50Hz |
| Power | 1200W |
| Dimension | 945mm×800mm×1450mm |
| Weight | 480Kg |
| Visual programming camera type | High pixel color CCD USB camera |
If you have secondery production demand and budget cost is not too much , this kind of machine very better for you .
Application field : IGBT modular , MEMS packaging, Large-power component ,LED light
Product features:
1. High performance double machine, the most suitable for large quantities of RC and SOP, SOIC, QFP and QFN mixed production
2 . Unique Y shaft belt drive structure, so that the movement of the driving force and the direction of the road overlap, reduce resistance, running more stable, more accurate. Y axis linkage rod by avoiding design, make fetching feeder more convenient
3. The feeder is open setting method, the intelligent optimization based on artificial optimization becomes possible, improve production efficiency.
4 . Configured with 2 groups of heads with special structure, the total weight of the headd is less than 800g, much faster.
5. Special heat sink design can make the equipment work continuously, unique electrical system design, convenient maintenance and system maintenance.
6. High precision and high speed servo motor drive is used to drive the industrial belt, which can effectively improve the precision of the chip and the speed of the circuit board.
7.Software operation is easy to learn .
8. Automatic visual online programming software, without manual input element coordinates, programming is simple, easy for beginners to convenient and practical, meet mass production of a variety of demand. To carry out a simple setting, you can achieve PCB fight board programming and paste.
9.PCB import is easy, fast, save the programming time.Improve mounting precision and speed according to the components,if open the image correction function.
10 The mounting order is controlled by software , The design of the software and hardware protection function of the device is caused by the loss of equipment caused by the loss of less .
11 Open operation and setup on the software interface to meet the requirements of different customers.
12 . Set the distance of PCB in the software.Choose different boards according to the Coordinate.
13 .With the lack of material monitoring function and manual mounting function, to meet different production requirements.
|
Configured with different feeders to meet the mounting requirement of different components. |
|
