Specifications
Capsule Pressure Gauges measure low range pressure from 250mmwc/25mbar to 10000mmwc/1000mbar.
Type : |
KP013 (micro pressure Gauge) |
Application: |
Low Pressure Gauges measure low range pressure from 250mmwc/25mbar to 10000mmwc/1000mbar. Common Applications include low pressure measurement of gas & liquid media which do not corrode brass, Burner monitoring, Gas production, Medical Applications, etc
|
Dial size: |
4", 6", and 160mm |
Pressure range: |
- 60mbar to 600 mbar |
Socket: |
Brass or stainless steel 316 |
Connection thread: |
NPT , BSP, BSPT and other special specification |
Capsule: |
Phosphor bronze or stainless steel 316 |
Case: |
Stainless steel 304, Black painted steel available |
Bezel: |
Flat bayonet ring SS304, Painted steel Flat bayonet ring available |
Window (lens): |
Tempered glass |
Dial plate: |
Single and dual scale (Psi, kPa, mbar, H2O) available |
Accuracy: |
1.6% full scale, 2.5% full scale |
Zero adjust: |
Adjustable on the dial |
|
Option Info: |
Other materials, ranges, connections are available upon request |
