Good Quality Mini Industry Washer From China

Henan Machinery & Equipment Company Limited
Good Quality Mini Industry Washer From China thumbnail-1
Good Quality Mini Industry Washer From China photo-1
US$ 1,500 - 8,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Place of Origin:
Henan, China
Brand Name:
MS
Contact Supplier Request Quote Chat Now
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao or other Chinese sea ports
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Place of Origin Henan, China
Brand Name MS
Model Number Mini industry washer from china
Feature Sudsing / Foaming
Fuel Electric
Certification CE
Use Other, washing and cleaning
Cleaning Process Cold Water Cleaning
Cleaning Type Immersion / Soak
Industry Used Other, industry
Material Other, textile
Power(W) 4kw
Dimension(L*W*H) 2500*1400*2100mm
After-sales Service Provided Engineers available to service machinery overseas



Machine In Factory

good quality Mini industry washer from china



Product Description

 Features of sheep wool washing machine

1. This sheep wool washing machine is horizontal drum style, The surface is made of the high-quality stainless steel plate, flat and smooth,corrosion proof and not damage the fabrics.

2. This sheep wool washing machineis safe and reliable, the safety locking apparatus is installed on the inner drum door, and electrical inter-locking apparatus is installed on the outer drum door. If the door isn't opened completely, the machine will not start, ifthe door is opened during the machine is running, the machine will stop running at once.

3. The safety boltof inner drum door is installed on the outer drum.

4. The driving system is driven via the motor transmission to two-step V-belt then to the main shaft of the rotating drum. It has the features of stable running, no noise anddurable.

5. The washing temperature and washing time of the machine is controlled automatically by the programmable controlling computer.

6. This sheep wool washing machine is installed with the water level meter, thus the operator can observe and control the water level.

7. The washing speed of the rotating drum can be adjusted as per the different washing technology requirements for the industrial washing machine with the transducer.





Technical Parameter

Model

Max.washing

Capacity(kg)

Drum  dimensions

(mm)

Speed

(r/min)

Power

(kw)

Steam  pressure

(MPa)

Overall  dimensions

(mm)

Whole  machine

Weight(kg)

MS-10

15

550*600

35

0.75

0.3-0.6

1100*850*1200

260

MS-20

20

550*700

35

0.75

0.3-0.6

1250*940*1300

380

MS-30

30

700*800

33

1.1

0.3-0.6

1650*1100*1450

600

MS-50

50

800*1000

33

1.5

0.3-0.6

2000*1300*1500

800

MS-80

80

950*1220

33

2.2

0.3-0.6

2050*1400*1800

900

MS-100

100

950*1420

33

3

0.3-0.6

2350*1400*1900

1200

MS-150

150

1080*1600

31

4

0.3-0.6

2500*1400*2100

1500

MS-200

200

1080*2000

31

5.5

0.3-0.6

2940*1480*2100

1950

MS-250

250

1200*2260

31

7.5

0.3-0.6

3140*1500*2300

2300

MS-300

300

1300*2260

29

11

0.3-0.6

3514*1850*2300

2600

MS-400

400

1460*2440

29

15

0.3-0.6

4200*2050*2450

3400



Working process

 Turn on the power switch, the switch light is on andthe stop light is also on.

The time screen shows the general setup time and thetemperature screen shows the setup temperature, the output relay are notworking, this is the very beginning situation.

Press thestarting/pause button, the starting light turns green.

The rotating drum and heating are both workable. Therotating drum must work according to the following cycle: positive rotating(setup time), stop (setup time) then negative rotating (setup time) and stop(setup time).

The heater will be controlled to work as per thepreset temperature. The drying time will be reduced gradually until 0.

Cut off the heating and rotating drum and alarming for1 minute, the stopping light is twinkling, the buzzer is alarming for 1 minuteand then the machine comes back to the very beginning situation.



detailed drawing

good quality Mini industry washer from china





The whole line

tIndustrial washing machine-Dewatering machine-Drying machine



good quality Mini industry washer from china



Washing machine

good quality Mini industry washer from china



Dewatering machine

good quality Mini industry washer from china



Drying machine



good quality Mini industry washer from china







Our Services

good quality Mini industry washer from china



FAQ
1 how long is the product warranty period ?

A: the product warranty period  is 12 months

2. I am a  foreign customers, if the machine works wrong, how your company resolved  ?

A: We have professional engineers abroad, after receiving your request, we will solve your problems at first time.

3. how much is  MOQ of your machine?

A:our machines MOQ  is 1 set and also support the mixed batch.

4.Where can we buy the machine's parts?

A: Our company can provide machines for your any time  We will send a professional and high levels

installation engineer team at the same time the product properly to the destination, in order to supply you

a full range of products installation services. For some typical problems, our rigorous installed engineers

also will do some certain installation debugging training, etc. Technological support
