LVD-CNC QC11Y/K 6x2500 Carbon Steel Plate Hydraulic Guillotine Shearing Machine
- 200 Set / Sets per Month
- Shanghai
- T/T L/C D/P D/A Credit Card PayPal
- 1600 ton Heavy Duty Hydraulic Used Car Body Cutting Gantry Shear Machine OEM Accecpted
- 1600 Ton Heavy Duty Hydraulic Used Car Shell Gantry Type Shear Machine OEM Available
- 4axis 5axis Large size and thickness(0-40mm) cnc plasma cutting machine
- Automatic cnc plasma cutting machine gate cnc router 120a/200a
- Fully automatic 20mm plasma cutting machine custom size high quality
- 200mm pipe table axe for plasma metal cutting machine spare parts in weifang
Product Details
Condition: | New | Place of Origin: | Anhui, China | Brand Name: | LVD-CNC |
Model Number: | QC11Y/K-6x2500mm | Voltage: | 380V | Rated Power: | 5.5kw |
Dimension(L*W*H): | 2600x1680x1750 | Weight: | 4200KG | Certification: | CE ISO |
Warranty: | 5 Years | After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
LVD-CNC QC11Y/K-6x2500 Carbon Steel Plate Hydraulic Guillotine Shearing Machine
Performance& features
guillotine beam design
- high precision, three-points rollers guide
whole welding structure
integration hydraulic system
motorized back gauge with digital show
manually blade clearance adjustment, easy to be operated
variable shearing angle to reduce the deformation of the shearing piece
upper knife carrier with inward structure, it does facilitate to feed the material
counter controlling the number of shearing
standard front extensive arms
four cutting edges blade to prolong working life
foot pedal with emergency stop
Standard Equipment
1. Variable rake design for machine |
2. Holland Delem DAC310, DAC360 Controller |
3. Motorized blade gap adjustment |
4. 750mm powered ball screw back gauge |
5. 130mm throat depth with side guards |
6. Adjustable stroke length and digital counter |
7. Powerful material holddowns |
8. Front squaring arm with scale and support arms |
9. Front finger guards |
10. Cutting line illumination |
11. Ball transfer table and T-slot |
Specification
MODEL | 6x2500 |
Thickness(mm) | 6 |
Width(mm) | 2500 |
Cutting Angel(°) | 1°30' |
Material Intension(KN/cm) | ≤450 |
Rear stopper ajustement(mm) | 20-750 |
Travel Times(Times/Min) | 14 |
Hold downs(Pcs) | 14 |
Main power(KW) | 7.5 |
Weight(Kg) | 4200 |
Overall dimension(mm)(L*W*H) | 3100x1725x1900 |
Mainly Components of LVD-CNC QC11Y/K-6x2500 Carbon Steel Plate Hydraulic Guillotine Shearing Machine
Main Motor: Import from Germany SIEMENS.High efficiency and energy saving | |
Ball Screw/Linear Guider: From Taiwan HIWIN, precision to ±0.01. | |
1. Work Table: With rolling beads, which is easy for plate feeding; 2. Front Fence: To protect worker safety.
| |
1. Shearing Machine Cylinder Pressure: To press the plate when cutting, which improve the cutting eage smooth; 2. Shearing Blade: 6CrW2Si. High temperature annealing |
|
Electrical power adjustable blade adge | |
Nitrogen Cylinder: Like the spring. compressed When under the pressure, promote cutting edge reset return |
|
Back Gauge: 3 Axes including blade gap, cutting angle, back gauge with optional front feeder and pneumatic back gauge support. | |
Hydraulic Valve: From Germany Rexroth |
|
Electrical Cabinet: Electrical components in line with international standards, safe and reliable, strong anti-jamming capability, electric control cabinet cooling function. | |
Control System:Delem DAC310 360CNC |
LVD-CNC QC11Y/K-6x2500 Carbon Steel Plate Hydraulic Guillotine Shearing Machine
Package Type: wooden package or can be adjust for the machine's safety.
Container Packaging: Wrapped in plastic to protect from getting wet.
Packaging Details: | 1)before packing,the machine tool will be testing for 48 hours to ensure all the equipment is 100% qualitied. 2)before loading,stable package,professional and skilled loader reduce damage of product during transport. 3)after loading,our professional documentary staff will follow the order till the product departs from port. |
Delivery Detail: | 30 days |
- Inquiring&consulting Service:24 hours online to reponse in 2 hours,provide solution in one day and solve complaint in 2 days.
- Technical Sevice: Engineers available to serive machinery overseas. We dispatch technician to customer's factory for installations and preoperation of machines.(costomers only need to pay airfare and hotel)
- Quality Guarantee Sevice:We provide 5 years warranty. We sign the agreement with detailed technical data.
- Other Service: A discount for a long cooperate and your visit to our factory is welcomed.
LVD-CNC QC11Y/K-6x2500 Carbon Steel Plate Hydraulic Guillotine Shearing Machine
ABOUT LVD-CNC
LVD-CNC is totally focused on providing a line of products and support to maximize the productivity of your Sheet metal machinery.
For over 16 years, LVD-CNC has specialized in CNC Press Brake, Guillotine and Laser Cutting and Punching to provide a complete sheet metal production workshop and improve accuracy of the productivity.
The company has a global network of over 15 appointed distributors trained to sell and service LVD-CNC machines.
LVD-CNC machines are built to our stringent set of design and quality standards in state-of-the-art manufacturing facilities.
LVD-CNC product designs combine accuracy, speed, flexibility, durability, reliability and advanced technology to deliver machines with the highest performance-to-price ratio in the industry.
