wire rope hoist load capacity 180kg lifting height 29m
This easily portable unit is designed for multiple-story construction work sites and long-lift applications for loads.The wire rope hoist can lift up to 180kg, lifting height 30m, easy easy to install, with a simple and straight forward control pad. It can hoist at 12m/min and is made of durable steel, making it a reliable and sturdy piece of equipment.
The capstan winchis a tough, highly portable unit that is perfect for the likes of utility machinery installation, overhead line crews, farm improvement, and transformer replacement.
ATX-250A, Cap.250kg is also available.
1. Model |
ATX-180A |
2. Load |
180KG |
3. Wire Rope dimension |
4mm*30m |
4. Speed |
12m/min |
5. Voltage |
AC 100-240V/50/60HZ |
6. Power Source |
1200W |
7. Lift Height |
29M |
8. Temperature Protection |
YES |
9. Net weight |
18.5KG |
10.Color |
Orange |
11. Packing Dimension |
477mm*265mm*280mm |
12. Certification |
CE ISO9001 |
Features
—Unique design and elegant shape makes the job of lifting or pulling materials, machine etc so
much easier and safer.
—Suspending style with protection hook, high tensile alloy galvanized wire rope ensures easy
installation and safe working.
—Strength Al-alloy shell makes it weight light, stand wear and tear.
—Temperature protection system extend a longer service life.
—Dual braking system and upper limit switch, provide a double protection, making it safer and
more reliable.
—All gears are made from high quality Alloy steel with hard surface, allowing it to work in a sealed
oil bath for a long time.
Experienced but Keep Original
Over 23 years in hardware manufacture and continue developing new styles in electric hoist and winch.
OEM is available due to skilled engineers and trained staffs.
Cost Down, Quality Up
Independently manufacture and export by us that will help you cost saving and more competitive in the market.
Only suppliers with good fame will we select to cooperate from raw material to packing.
Mature management ensures a smooth production.
Testing systems are established to ensure finished product are in good quality.
These build up our confidence.
Service within 24 hours
We promise to feedback within 24 hours from Monday to Saturday.
Pulling, Lifting, Energy Saving! Easy you take, Safety we care!
Q: What is our factory product range?
A: Mini electric wire rope hoist, suspending electric hoist, wire rope winch, vertical lifting AC winch remote control etc.
Q: What information should I provide if I want to order the products?
A:1) Product information: Quantity, Model No. , Specification (capacity, lifting height, voltage, size, material, color and packing requirements),
2) Delivery time required.
3) Shipping information: Company name, Address, Phone number, Destination seaport/air port.
4) Forwarder's contact details if there is any in China.
Q: How about your payment terms?
A: For trial sample order, 100% advance, via Western Union is preferred.
For bulk order, 30% deposit, with the balance before delivery, via TT.
Q: Can I use our own logo?
A:Yes, we can produce by using your own logo.
Q: What’s the sample policy?
A: We can send you 1pc of sample for your test, but you need to pay for the sample fee and delivery expenses, as it's our company's rule. Pls contact us for the sample details.
