Help CenterIntelligent Long-stroke Tower Pumping Unit
Related Products
-
CYJ Pumping Unit Used in Oil LandNegotiableMOQ: 1 Set -
API B Series Oilland Pump JackNegotiableMOQ: 1 Set
-
China Manufacturers API C Series Oilland Pump JackNegotiableMOQ: 1 Set
-
Double-horse Pumping Unit Used in Oil LandNegotiableMOQ: 1 Set
-
API 11E C Type Crank Balance Oil Pumping UnitUS$ 20000.00 - 20000.00MOQ: 1 Set
The intelligent long-stroke pumping unit produced by Henan Sike Petroleum Environmental-Protection Equipment Co.,Ltd. (hereinafter referred to as the tower type pumping unit),has the characteristics of low consumption of steel, long stroke, variable of stroke frequency, large load, high efficiency, low energy consumption, and easy operation. This tower type pumping unit is suitable for extraction of crude oil both onshore and offshore.
Tower type pumping unit is driven by permanent-magnet synchronism motor and high efficiency Vector frequency converter with excellent power supply. According to the working condition of oil well, the control system will automatically adjust the output torque and ensure the motor operation in best condition and boost the fill factor of pump and make the obtained indicator diagram to ideal diagram.
The permanent-magnet synchronism motor, which is the Tower type pumping unit engine, is with European technology and represents the application of the aerospace scientific achievements in the civilian industry products. The promotion and application of such technology is an innovative revolutionary reform in the motor traction field, so in the driving field, the old and heavy reduction gear casing are being replaced by the permanent-magnet synchronism motor with large torque and low speed.
Restructured from SINOPEC in 1997, Puyang Zhongshi Group Co., Ltd has 18 years manufacturing experience of petroleum machinery products till now, we have competitive prices of our main products of Pumping Units,Subsurface sucker rod pump,wellhead,cementing accessories,etc.
We have certificates of API 5CT,6A,10D,11AX,11E, ISO 14001 and 9001,and HSE certificates.
With 10 years exporting experience,we have exported to more than 30 countries such as USA,Middle East,Southeast Asia,Russia,etc.
Drive systerm
Drive system includes the motor pulley, large pulley, driving wheel and bearing block.
Low rotating speed, high torque. The motor drives driving wheels by belt and no need of reductor gear.
Balance systerm
consists of suspension bracket, flexibility rail, balance box, guild rail wheel, safety tongs and balancing weight.
Allan among pump parts
Same parts with same shape are strapped via steel bar to reduce its space.
Allan before open top container
To load more pumpers in to container,we usually use open top container for easy loading.
Reinforce unassembled pumper
We use steel bar to fasten strapped pump parts to container in case they move during transport.
