Specifications
1.Simple structure2.High accuracy and reliability
3.Good price
4.Medium:air and liquid
Product Pictures of digital china vortex shedding flow meter
Product Description of digital china vortex shedding flow meter
Introduction
Digital chorine gas digital china vortex shedding flow meter measuring instrument / tool is an internationally advanced new type of flowmeter, it is developed based on Karman Vortex Street Theory. It is applicable to the measurement of superheated steam, saturated steam, general gas and liquid.
Features
a) Simple structure, no moving parts;
b) High accuracy , high reliability, no need of field debugging;
c) Capable of remote transmission of flow signal, able to make network with computer to implement central administration;
d) Unique design of amplify board, applicable to both gas and liquid.
Specification
Item |
Compact type |
Remote type |
||
Flange connection |
Flange clamped |
Inserted type |
||
Caliber(mm) |
15~2000 |
125~2000 |
15~2000 |
|
Pressure(MPa) |
1.6MPa, 2.5MPa, 4.0MPa and above |
|||
Accuracy |
±1.5%, ±1.0% |
|||
Applicable Medium |
Superheated steam, Saturated steam, General gas and liquid |
|||
Medium Temperature |
-40°C~+350°C |
|||
Ambient Temperature |
-30°C~+65°C for voltage pulse output, -10°C~+55°C for current output, |
|||
Power Supply |
12~24V DC, 3.6V Lithium battery |
12~24V DC |
||
Signal Output |
Standard current, 4~20mA |
Voltage pulse, low level≤1V, high level≥6V, load resistor>150Ω; |
||
Display |
Two-line LCD local display. |
Remote transmission. |
||
Explosion-proof Grade |
IaⅡCT6(intrinsically safe explosion-proof) |
non |
||
Company information
- We have been in this business for more than ten years.
- Our customer satisfaction is 99. 5%.
- We are located in Kaifeng, the most ancient and biggest base of flow instrument in China, which means we have full access to the most advanced technologies in this field.
- We are awarded ISO9001:2008.
- Our belief is "Accuracy and Attitude, Access to Customer".
- Our monthly output of vortex flow meters is 2000 sets.
- We are able to provide electromagnetic flow meters with international standards.
- Our goal is to make world wide brand.
Table2: Density of common gas 20°C, absolute pressure p=0.1MPa
Gas Name |
Density(kg/m3) |
Gas Name |
Density(kg/m3) |
Air(dry) |
1.2928 |
Ethyne |
0.1717 |
Nitrogen |
1.2506 |
Methane |
0.7167 |
Hydrogen |
0.0899 |
Ethane |
1.3567 |
Oxygen |
1.4289 |
Propane |
2.005 |
Chlorine |
3.214 |
Ethene |
1.2604 |
Ammonia |
0.771 |
Propylene |
1.914 |
Carbonic oxide |
1.97704 |
Natural gas |
0.828 |
Carbonic dioxide |
1.3401 |
Coal gas |
0.802 |
More Products for You to Choose
Why Choose Us
We have been in this business for more than ten years.
Our customer satisfaction is 99. 5%.
We are located in Kaifeng, the most ancient and biggest base of flow instrument in China, which means we have full access to the most advanced technologies in this field.
We are awarded ISO9001:2008.
Our belief is "Accuracy and Attitude, Access to Customer".
Our monthly output of electromagnetic flow meters is 3000 sets.
We are able to provide electromagnetic flow meters with international standards.
Our goal is to make world wide brand.
Packaging & Shipping
1.Packing:export plywood case packaging,including instructions and certificates
2.Delivery Time:Within1-20 sets electromangetic flow meters,2-7 wording days after payment
3.Shipment:Express(FedEx,DHL,UPS&TNT),by air/ocean or other methods available
