5mm Cds Photoresistors With Metal Cap

Name: 5mm Cds Photoresistors With Metal Cap
Brand: LIDA
SKU: 111447959

US$ 0.5 - 1 MOQ: 100 Pieces

Key Specifications

Place of Origin:

Henan, China

Brand Name:

LIDA

Model Number:

5mm photocells

Lida Optical And Electronic Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

SHENZHEN

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Henan, China

Brand Name LIDA

Model Number 5mm photocells

Type Photoresistor

Technology Ceramic Composition

Package Type Throught Hole

Specifications

A photoresistor, often referred to as a light dependent resistor, is a resistor that reacts to increased exposure to light.

Specifications:

GL5516:
- Ron at 10lux: 5 to 12kΩ
- Roff (minimum): 0.2MΩ
- γ (100 to 10lux): 0.6
GL5528:
- Ron at 10lux: 10 to 20kΩ
- Roff (minimum): 1.0MΩ
- γ (100 to 10lux): 0.65
GL5537-1:
- Ron at 10lux: 18 to 35kΩ
- Roff (minimum): 2MΩ
- γ (100 to 10Lux): 0.7
GL5537-2:
- Ron at 10lux: 30 to 50kΩ
- Roff (minimum): 2MΩ
- γ (100 to 10lux): 0.7
Power dissipation (at 25 degrees C): 100mW
Maximum voltage (at 25 degrees C): 150V DC/AC
Spectral response peak (at 25 degrees C): 540nm
Ambient temperature: -30 to 70 degrees C
Performance:
- Peak wavelengths: 515, 550, 615 and 690nm
- Light resistance: measured at 10lux with standard light A (2,856K color temperature) and 2-hour pre-illumination at 400 to 600lux prior testing
- Dark resistance: measured 10 seconds after closed 10lux
- Error of γ: ±0.1
- Responsive to very low light (moonlight) and very high light levels (sunlight)
- Wide dynamic range
Applications:
- Dusk to dawn light switching
- Ambient light sensing
- Night light control
- Automatic rear view mirror
Packing:
- Type: ceramic
- Mounting option: through holes (plug-in)
