The waste tire recycling machine line
The world’s economy grows and the car price is change to be more cheaper, the car is very popular. But the scrap tires were polluted environment, our production soles this problem and converting it into wire steel and rubber powder. can reuse the scrap tire to change the second economy. Power can make reclaimed rubber and engineering rubber products etc.
Drawing wire steel-cutter-the first crusher-fine crusher-dust collector-separator-rubber powder and fibrous collector
The waste tires value
The waste rubber can create renewable resources of society. Waste tire containing 22% ~ nylon 24% synthetic fiber can be processed into plastic products, 16% ~ 24% of the wire can be used as high quality spring material, 58% ~ 60% of the rubber mixture can produce reclaimed rubber and rubber powder (granule). 3 tons of reclaimed rubber can replace 1 tons of natural rubber.
The machine line consist of :
1: Drawing machine; 1 Cutter; 1 Belt; 1; MX 800 intelligent crusher; 1; fine crusher; 1 dust collector; 1 magnetic separator; 1 vibration separator; 1; fibre collector.
Waste tire resource recycling equipment
1. Technique Introduction
It is an integrative equipment for tire grinding and metal and rubber separation. At first tires are drawing steel wire by automatic machine. Then scrap tires go to cutting and go to coarse crushing, fine crushing. Finally rubber powder and metal can be obtained. This equipment has been combined the most advanced grinding and separation techniques in the world and adopted unique process technique. It works in enclosed environment and no waste water, dusty and poisonous gas give off during production.
2. Technical Specifications:
Model No. MX 800
Process Capacity (kg/hr) 600kg; 1000kg
Dimension (L*W*H)/m 24x6x3
Power Consumption (kw) 380v/102KW
Operators 3
Metal Recovery Rate 97%-99%
Metal Content of Non-metal Powder <1%
Granularity of rubber (mm) 1-2 mm
3. Environmental Protection Standards
A. Emitted exhaust gas consists with secondary standard of “Emission Standard of Air Pollutant” (GB16297-1996)
B. The equipment uses negative pressure transportation, no dust in operation environment. Slight dust leak in the outlet can be manually controlled.
C. Generated noise consists with “Light Industry Machinery Condition” (GB/T 14253-2008)
D. The waste electronic treats recycling with secondary standard of “treatment standard of stock& disposal (GB 18599-2001)
4. Characteristics and Benefits
A. The drawing machine can remove steel wire from tire, could be easy crush and keeping the high value steel wire. Adopt remove dusty and collect fibre and then fine crush.
B. National Environment Protection Standard achieved. No dust leak and no secondary pollution such as waste water and exhaust gas.
C. Low energy consumption but high production.
D. High metal recovery rate which reaches 96%-98%. Metal content in non-metal powder is less than 1%.
