Low price Outer diameter 400 to 2000mm gravity spiral chute for metals and nonmetal ore
1. spiral chute — Product advantages
1.Less floor space; easy and stable operation; rational configuration; convenient installation
2.High processing capacity and efficiency
3.Moisture proof, antirust, corrosion resistant, adaptive, noiseless
2. spiral chute — Product feature
Spiral chute (glass fiber reinforced plastics spiral chute) present advantages as follows: less floor space; easy and stable operation; rational configuration; convenient installation; high processing capacity and efficiency; moisture proof; antirust; corrosion resistant; adaptive and noiseless, etc.
3. spiral chute — Product application
Spiral chute (glass fiber reinforced plastics spiral chute) is applicable to metal and non-metal ores with adequate density difference, like iron, chromite, pyrite, tin ore, tungsten, tantalum, niobium, gold ore, colliery, monazite, rutile and Zirconium.
The techincal parameters of spiral chute
model | Sll-2000 | 5LL-1500 | 5LL-1200 | 5LL-900 | 5LL-600 | 5LL-400 | |
External diameter(mm) | 2000 | 1500 | 1200 | 900 | 600 | 400 | |
Screw pitch(mm) | 1200 | 540,720 | 900,720,540 | 675,540,405 | 450,360,270 | 240,180 | |
Ratio of screw pitch to diameter | 0.6 | 0.36,0.48 | 0.75,0.6,0.45 | 0.75,0.6,0.45 | 0.75,0.6,0.45 | 0.6,0.45 | |
Horizontal Angle(°) | 9° | 9° | 9° | 9° | 9° | 9° | |
Spiral head number | 3 | 4-2 | 4 | 4 | 4 | 4 | |
Feeding Particle Size (mm) | 2.0-0.04 | 0.3-0.02 | 0.3-0.03 | 0.3-0.03 | 0.2-0.02 | 0.2-0.02 | |
Feeding concentration(%) | 30-55 | 25-55 | 25-55 | 25-55 | 25-55 | 25-55 | |
Processing Capacity (ton/hour) | 10 | 8-16 | 4-6 | 2-3 | 0.8-1.2 | 0.15-0.2 | |
Overall dimension | length(mm) | 2120 | 1560 | 1360 | 1060 | 700 | 460 |
| width(mm) | 2120 | 1560 | 1360 | 1060 | 700 | 460 |
| height(mm) | 5600 | 5230 | 5230 | 4000 | 26000 | 1500 |
weight(KG) | 900 | 800 | 600 | 400 | 150 | 50 | |
