Vibration Screen Price and Manufacture MX2-1225

Vibration Screen Price and Manufacture MX2-1225 thumbnail-1
Vibration Screen Price and Manufacture MX2-1225 thumbnail-2
Vibration Screen Price and Manufacture MX2-1225 photo-1
Vibration Screen Price and Manufacture MX2-1225 photo-2
US$ 650 - 5,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Type:
Circular
Application:
Ore
Contact Supplier Request Quote Chat Now
Jiangxi Mingxin Metallurgy Equipment Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Xiamen Port
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Type Circular
Application Ore
Place of Origin Jiangxi, China
Brand Name MX
Model Number MX-1225
Voltage 380v 50hz or customize
Power(W) 5.5kw
Dimension(L*W*H) 2702*1714*740
Weight 1300kg
Certification ISO, SGS
Warranty 12 months
After-sales Service Provided Engineers available to service machinery overseas

Vibrating Screen Filter Machine MX2-918



Specifications

Vibrating screen
1.type: vibrating screen
2.layers:1, 2 stainless steel layer
3.for sand size filter
4.ISO



Production Description

The vibrating screen moves on a circular motion. So it is also called circular vibrating screen. It is a multi-layer and high efficient vibrating screen. Advantages are: stable structure, strong exciting force, high efficiency, safety, easy to maintain and durability; circular vibrating screen has been widely used in mine, construction, transportation, energy and chemical industries.



Application

Vibrating screen is widely used for grading and screening materials in the following fields: minerals, quarry, building materials, water conservancy and hydropower, transportation, chemical industry, smelting and so on.

 Vibration Screen Price and Manufacture MX2-1225





Vibrating Screen separator features and benefits:

1) Materials blocked in meshes can be automatically out;
2) Simple structure and easy to disassemble and replace;
3) Electricity power consumption is less.

4)No powder dispersed, automobile discharged.



Working principle of vibratory screen separator:
The vibrating screen consists of screen box, supporting device, vibration exciter, transmission part, etc. The barrel-type vibration exciter is installed in the middle part of the machine. During normal operation, the vibartion of exciter will drive the screen mesh fixed on the screen box vibrate, and then materials will be screened. The big and small materials fall from the upper side and lower side of the screen to get them separated.



Specifications of Vibrating screen separator

Model

Screen size (mm)

No. of Layer

Screen mesh (mm)

Max. feed size(mm)

Capacity   (t/h)

Motor power (kw)

Vibrating frequency (r/min)

Double amplitude(mm)

MX1-612

600×1200

1

1-25

40

10-20

1.5

1000

6

MX2-612

600×1200

2

1-25

40

10-20

1.5

1000

6

MX1-918

900×1800

1

1-25

40

20-25

2.2

1000

6

MX2-918

900×1800

2

1-25

40

20-30

3

1000

6

MX1-1250

1250×2500

1

5-40

100

150

5.5

850

2-7

MX2-1250

1250×2500

2

5-50

150

150

5.5

850

2-7

MX1-1530

1500×3000

1

1-40

100

220

7.5

850

8



Equipments Photos

Vibration Screen Price and Manufacture MX2-1225



Other Mining Machines

Vibration Screen Price and Manufacture MX2-1225



Exbitions

Vibration Screen Price and Manufacture MX2-1225

Contact Us

Vibration Screen Price and Manufacture MX2-1225
