pa system IP Intercom System,electronic paging system,guest paging system,waiter paging system
Application:
Professional dial-up network to the point, intercom, multicast, and broadcast terminal;
Suitable for indoor and outdoor environments to install, can use for two-way intercom communication ;
Features:
1. Appearance neat, beautiful lines, durable, desktop and wall-mounted optional;
2.TFT color screen display, screen-friendly, high-keyboard design, 21 pieces of numeric keys and function keys, display clearly, easy to operate;
3.Built-in high-level speakers, 10 electronic volume control;
4. The device uses an embedded linux technology and DSP audio processing technology design; using industrial-grade chips;
5.Numeric keypad dialing, call any terminal, achieve full-duplex intercom;
6.Can be connected to an external speaker, voice calls are clear and loud;
7. Built-in high sensitivity microphone, wide area of the sound capture, high sound reproduction ;
8.Support wired network and WIFI wireless internet access modes;
9.Support four ways to get tracks : the server, local memory, U disk and line in
10.Support remote unicast, multicast and all broadcast in a LAN environment ;
11.Two kinds of working modes: online and offline, still can perform timing tasks when there is a failure of network.
12.One audio auxiliary output, external expansion to active speakers or headphones;
13.One local signal input, achieve external audio input and implement the local emergency broadcast input;
14. a DC5V power supply interface;
15. Can connect to the Ethernet wherever there is a Ethernet port, support cross-segment and cross-routing.
Technical parameters:
Model |
OBT-9808 |
Network Interface |
Standard RJ45 |
Protocol Support |
TCP/IP,UDP,IGMP(group broadcasting) |
Audio Model |
MP3 |
8K~96KHz |
|
Transmit Speed |
10/100Mbps |
Audio Format |
16 digit stereo CD tone |
Output Frequency |
20Hz~18KHz |
THD |
≤0.2% |
Noise Signal Rate |
>80dB |
350mV RCA Screw terminals |
|
|
Speaker Output Impedance and Rated Power Output
|
8Ω,RCA Screw terminals |
Line Out Voltage Input |
1000mV 3.5 Screw terminals |
Line Out Resistance Input |
1KΩ |
MIC Input Sensitivity |
10mV |
Working Temperature |
5°C~40°C |
Working Humidity |
10%~90% |
Power Consumption |
10W |
Standby Power Consumption |
≤1W |
Power Supply |
DC5V |
Dimensions |
430×110×165mm |
Weight |
1Kg |
Price
On the basis of FOB Shenzhen
Payment:
We accept T/T (30% deposit, 70% before loading ),If you prefer other payment ways, we can talk about it
Lead time :
Sample Lead time:7 days
Production lead time:30 days
MOQ:
There is no MOQ for our esteemed customer
Warranty:
We provide 2 years’ warranty for our esteemed customer
The APP of OBTPA IP network public address system in university
Pictures of OBTPA factory and our certifications
OBTPA at exhibition
Main products of OBTPA
Any shipment you want
Any payment you want
We have answers for your FAQs
Q:May we become an OBTPA Distributor?
A:Yes, you will be most welcomed in our Network of Distributors. Please let us know about your interest in becoming one of them. We are very keen to broaden our sales network and we will be very happy to have you as our esteemed distributor.
Q:Does OBTPA provide Technical Training for its clients and distributors?
A:Yes. Providing technical training to our Distributors is a very important matter for us. We provide training seminars in our factories upon requests and also at scheduled times. These training seminars are free of charge for the attendants who only have to take care of their own transportation and hotels costs. Please contact us if you are interested in attending one of these seminars. Also we provide teaching videos to our customers. For some difficult questions, we can arrange meetings between our customers and our engineers through phone.Skype or MSN.
Q:Does OBTPA provide Commercial Training for its clients and distributors?
A:Yes. This can be done during a previously arranged Technical Training, as mentioned above, or as a separate event. Please contact us if you are interested in attending one of these seminars.
Q:Is it possible to organize in-house training for our engineers and salesmen?
A:Yes, we can accommodate to this request. However, charges may apply. Please ask for conditions.
Q:What is the warranty of the OBTPA products?
A: Please see our quality commitment as follows:
Ensure our products and technical services assume full responsibility for the quality.
For the products from the date of acceptance, the warranty period is two years, if quality problems occurred within one year, we provide free replacement parts; If warranty expires, the supplier will provide maintenance / repair services, only charge for material cost;
Q:What standards do the OBTPA products and systems comply with?
A: Our products comply with CE standards, CCC standards and contract requirements, We produce the products which can meet the customers's satisfaction. And our company have got the certification of ISO9001,ISO14001,ISO18001 ,CCC and CE.
Q:Can the OBTPA products and systems be integrated with other systems like Fire Alarm, Building Management Systems and so on?
A:Yes, they can be integrated with other systems through several different ways
