Temperature Sensor

Specifications

1,Temperature Sensor
2,Metal Shell NTC coating
3,High-reliability NTC thermistor with the PVC wires
4,high sensitivity



1. Temperature Sensor
2. Stainless steel 5x40mm or coustomer request.
3. Metal Shell NTC Temperature Sensor, Ideal for Wide Temperature Control
4. Wide operating temperature range: -30 to 150°C

5. Parameter range:

   R25°C: 100 ohms to 2,000K ohms

   B25/85: 2,800 to 4,500K

6. Connect the high-precision
7. Quick response, high sensitivity
8. High-reliability NTC thermistor with the PVC wires
9. Then wrap with insulated, heat conductive and water-resistant materials into the shape you need to facilitate the installation and long distance temperature measurement and cont
10. Applications: refrigerator, air conditioner, unitary bathroom, medical apparatus, and instruments, floor heating thermostat, soil temperature, water temperature, and so on.
